RS232 Middle Range UHF RFID Reader for Parking Lot
RS232 Middle Range UHF RFID Reader for Parking Lot
MR6221E UHF RFID
reader based on new generation reader technology platform development.
Combined UHF
RFID advanced technology and many years experiences based on RFID market.
MR6221E UHF long
range integrated RFID reader is more stable and can be used in various
applications
RFID reader communicates
wirelessly through the antenna and RFID tag
Realizing the
read of tag identification codes and memory data, controlling unit and the reader
antenna.
The electromagnetic
clutch is coupled with radar principle.
UHF RFID Reader Specification
Model No.: MR6221E
Frequency: US(902~928MHz),
China(920~925MHz), EU(865~868MHz), customized
Protocol: ISO18000-6C, EPC G2
RF Power: 0~31dBm adjustable
Sensitivity: -80dBm(9dBi antenna more
than 6m)
Read Speed: Multi-tag
200pcs/second,single tag 2000times/minute
Processor: ARM CORTEXM3 100MCPU
Memory: 16KB tag data memory and
32KB ferroelectric memory
Data
Interface: 100M Ethernet interface(TCP/IP), RS232/RS485, Wiegand26/34
One
team input and one team output(TTL),one team Relay
Dimension: 280*280*68.5mm
Power Supply: DC+9V~+15V
Working Temp.: -20℃~60℃
Certifications: FCC, CE, CCC
Our Advantage
1.Built-in 9dBi
linear polarization antenna
2.Reading range of 6 meters
3.Waterproof & Dust-proof
4.Easy using for
vehicle tracking
5.Microwave RFID
card reader reaches strong penetrability
6.Long
communication distance and anti-collision performance
7.Strong security
stability and fast reading speed
Application
1.Safe City 2. Auto Park 3. Vehicle Tracking System
