SCB200/200 2t Double Cages Construction Hoist with Frequency Converter

SCB200/200 is double cage frenquency type building hoist. max load for per cage is 2000kg, basic height 50m, max height up to 200m. mast section 650*1508mm. With variable frequency motor driven, it reach the lower speed of 36m/min, the middle speed of 45m/min, 63m/min and the high speed of 96 m/min.



SCB200/200 2t Double Cages Construction Hoist with Frequency Converter


SC200/200 frequency conversion construction hoist/building lifts//building lifts//building elevator


The performance parameters of SCB200/200 construction hoist

model

SCB200/200

Type

Gear rack type double drives double cages construction hoist









Working performance

Rated loading capacity

2*2t (2 cage, each cage holds 2t material)

Number of passengers

2*24 (2 cage, each cage holds 24 persons)

Rated start lifting speed

33/45/63/96(m/min)

Rated lifting height

300m (commodity supplying height 50m)

Hanging cage size(length*width*height)

3.2*1.5*2.4(m)

3*1.3*2.4(m)

3*1.3*2.1(m)

Basic height

50m

Max height

300m

Mast section

800*800*1508(mm)

Mast section weight

150kg

motor

Motor power

11*3*2(Kw)

Model of safety device

SAJ40-1.2


SC200/200 construction lifts Advantages

1. SC200/200 construction lifts havecomprehensive and reliable electrical, mechanical interlock device,safety switches and protection hook interlock switches.

2. advanced progressive anti-crash safetydevice, a flexible and reliable overload protection devices and advancedcomputer automatically call-layer devices.

3. simple struction, controllermicroprocessor, photo-electric signal input

4. have the protective function ofpreventing illegal operation

5.superior anti-jamming performance

6. electronic calling devices to make thehoists accurately arrive the floor, and increase the work efficiency.

7.paint of cages and mast section process Pickling phosphating,it will be more smooth, and more durable for about 5 years.

8. mast section apply new CNC stamping technology, connectionwill be more accurate and firm.


Our Service

 ----timely delivery, in time shipping notice

 ----1 year warranty of products quality and full set ofspare parts

 ----training installation, guidance of operation and maintenance

 ----engineers have rich experience, can solveall your problems

  As a professional exporter,our target is to serve worldwide clients with high-quality products, great-reliability, devoted responsibility,professional services and honorable credibility to meet customers’ requirements in all aspects. We will supply you 24 hours a day and 7 days a week after-sale services.

Looking forward your kindly inquiry and hope to help your strong business in near future!
