Schneider ELAU MAX-4/11/03/032/99/1/1/00 Motion controller

Core Features

• ✓  99-axis ultra-large capacity synchronous control: A single controller can manage up to 99 servos, supporting the storage and dynamic switching of a large number of electronic cam curves, and stably completing complex multi-axis processes such as electronic gear, tracking synchronization, constant tension closed loop, and high-speed flying shear cutting.
• ✓  Integrated onboard I/O channels: It comes with multiple digital DI/DO + 2AI/2AO analog interfaces, which can directly acquire tension, pressure and temperature analog signals without the need for additional analog expansion modules, simplifying control cabinet wiring.
• ✓  IEC61131-3 Standardized Programming: Supports mainstream programming methods such as structured text, ladder diagrams, and function blocks; logic operations and motion control are executed in parallel, resulting in fast real-time response.
• ✓  Modular installation with standard DIN rails: The unit has a neat structure, making it suitable for large electrical control cabinets with multiple controllers arranged densely, and it is easy to disassemble and maintain.
•

Q: What is the maximum number of servo axes that the MAX-4/11/03/032/99/1/1/00 can control, and what is its program storage space?

A: The "99" in the model number indicates that it supports a maximum of 99 servo axes for synchronous linkage. It has a built-in 32KB program storage space, which can store cam curves and production recipe motion programs for medium-sized equipment, and is compatible with multi-axis large-scale automated equipment.

Q: Does the MAX-4/11/03/032/99/1/1/00 have built-in analog input channels? Is an expansion module needed to acquire sensor signals?

A: It has 2 built-in analog inputs and 2 analog outputs, along with 20 digital inputs and 16 digital outputs. It can be directly connected to tension and pressure analog sensors without the need for additional analog expansion modules.

Q: What communication interfaces does the MAX-4/11/03/032/99/1/1/00 have, and what external devices can it connect to?

A: It integrates multiple interfaces including SERCOS servo bus, Ethernet, Profibus DP, CANopen, and RS485, allowing connection to HMI touchscreens, host control computers, third-party frequency converters, and digital sensor acquisition modules.
