MAX-4/11/03/128/08/1/1/00 is a Schneider Electric ELAU PacDrive MAX-4 series small-to-medium-sized integrated motion controller. It features a German-made control unit, a 32-bit hard real-time processor, 128KB of built-in program memory, and supports up to 8-axis servo synchronous linkage. The model suffix "1/1" indicates that it has complete digital I/O + analog channels. Utilizing the SERCOS III bus and compatible with the VDM series of servo drives, it is suitable for small to medium-sized packaging, printing, and pharmaceutical equipment with up to 8 axes. The VxWorks real-time system ensures an extremely short motion cycle of 250μs, stably completing conventional high-speed synchronous processes such as flying shears, electronic cams, and synchronous feeding.
Frequently Asked Questions
Q: Which I/O channels does the MAX-4/11/03/128/08/1/1/00 have, and does it require an external analog expansion module?
A: It has 20 built-in digital inputs and 16 digital outputs, and also integrates 2 analog inputs and 2 analog outputs, allowing direct acquisition of tension and pressure analog signals without the need for an additional analog expansion module.
Q: What debugging and diagnostic tools does the MAX-4/11/03/128/08/1/1/00 come with?
A: It has a built-in 8-channel software waveform oscilloscope that allows real-time observation of servo operation waveforms and automatically stores complete fault logs. Combined with the machine's status indicator lights, it facilitates quick troubleshooting of bus, servo, and I/O point faults.
Q: What are the installation environment restrictions for MAX-4/11/03/128/08/1/1/00?
A: It is designed for vertical installation using DIN rails, with an IP20 protection rating. It can only be placed inside a sealed electrical control cabinet. The operating ambient temperature is 0~50℃, and the environment must be dry, free from condensation, dust, and moisture.
