Description
|
|
Model
|
SSC50S
|
Safety Control Unit (for Vnet/IP, Rack Mountable Type)
|
|
Suffix Codes
|
-S
|
Standard Type (-20 to 40 °C) (with ISA Standard G3 )
|
|
-F
|
Wide range temperature (-20 to 70 °C) type (with Fan unit and ISA Standard G3)
|
|
2
|
Dual-redundant power supply
|
|
5
|
With no explosion protection
|
|
E
|
With explosion protection
|
|
1
|
100-120 V AC power supply
|
|
2
|
220-240 V AC power supply
|
|
4
|
24 V DC power supply
|
|
3
|
CFS1100 Safety Control Function License (for R3: R3.02.31 or later) (*1)
|
|
4
|
Without Safety Control Function License (for R4.01.31 or later) (*2)
|
|
Option Code
|
/ATDOC
|
Explosion Protection Manual
|
Note: Install the 19-inch rack mountable type devices in a keyed metallic cabinet to conform to the safety standards, the EMC conformity standards and the explosion protection standards.
For details, refer to ProSafe-RS Installation Guidance (TI 32P01J10-01EN).
Note: Select the option code “/ATDOC” to follow the ATEX Directive for use in potentially explosive atmospheres.
Note: When the release number is earlier than R3.02.31 or R4.01.31, use SCP451-1 as a processor module.
When the release number is R3.02.31 and R4.01.31 or later, use SCP451-1 or SCP451-3 as a processor module.
SCP451-1 and SCP451-3 can be placed in the same safety control unit.
*1: R3.02.31 patch software must be applied.
*2 R4.01.31 patch software must be applied.
