Description:
Filtering accuracy: The filtering accuracy is 6 microns, which can effectively remove fine impurities and moisture from the fuel.
Product features: It adopts a three-tube filter element structure, possibly offering more efficient filtering performance and oil-water separation capabilities. The filter element material is paper core, which can effectively adsorb and intercept impurities and moisture. The bottom has an embedded design, with the inner and outer filter elements embedded at the bottom, ensuring no residue during filtration.
Alternative models: It can replace various models such as N4442, R6353160, and P6353150 of fuel water separators.
Product Information：
| Part Number |
1000105 FCS477 |
| Filter Type |
Three-tube filter element fuel/water separator |
| Size |
Diameter: 80mm
Height: 210mm
Plate screw thread size: Return oil pipe 8MM / Inlet oil pipe 10MM, Outlet oil pipe 10MM
Filter Info: Diesel filter, 15 microns, three-layer high-efficiency, long-lasting
Product weight per unit: 0.4kg
Product weight for a complete set: 9.6kg
Number of items per box: 24 per set
Inner box, outer box dimensions and volume: 9*9*20.5cm / 56*38*22cm / 0.044352m3
|
| Cross Reference |
FCS477
HDF904
WK829/3
HDF924
ADG02342
CX0707
F5100-1105100
UF0039-Z1
W3000-1105100
CN3C159155BA
1000105FA
TF-8912
N4442
R6353160
P6353150
R6353231
PS9451
31390H1951
C2S27643
CN3C15-9155BA
OK52-A1-3480
06830806
F62870
3139-H1970
|
| Application |
Yuchai 4F / Delphi, Jiangling Full Van, Ford F-150, Ford, Hyundai, Jaguar, Kia, Ssangyong, Tata |
Our Service
 |
 |
 |
 |
|
Sample Delivery: 3-15 days.
|
Order Delivery: 20-30 working days, depending on quantity.
|
Shipping: Available by sea, air, or express.
|
Test the products upon receipt and contact us if there are any issues. |
