Description:
◆Double USB communication interface, the input of serial
port on the left, the output of keyboard on the right. ◆The data is output on the different format.
◆It is convenient for carrying, supplying the power by
USB.
◆It is stable for reading and writing the data.
◆Supporting IS0-18000-6C(EPC C1 GEN2)
Feature:
◆Compatibility with multiple protocols, easy
portable, high speed of reading/writing, using in every RFID system
◆Providing all kinds of keyboard format
◆Providing demo, SDK, C+, C#, Java etc.,
Specification:
|
Item No.
|
JT-6212
|
|
Performance Parameters
|
|
|
Working
Frequency
|
902~928 MHz or
865~868MHz
|
|
Antenna gain
|
3dBi circular
polarization
|
|
Protocol
|
ISO18000-6C(EPC
C1 GEN2)
|
|
Communication
port
|
Left USB to
serial port / Right USB to keyboard input
|
|
Software &
SDK
|
DEMO and C#, VC,
VB, Java, DELPH, etc.,
|
|
Encryption
|
Can be directly
encrypted, copy prevention.
|
|
Reading range
|
Stable reading
60~80cm
|
|
Writing range
|
Stable writing
0~10cm
|
|
Physical
parameters:
|
|
|
Power
|
USB
|
|
Output power
|
0~18±1dBm
|
|
Working
temperature
|
-20℃~+75℃
|
|
Storage
temperature
|
-40℃~+85℃
|
|
Item size
|
120x78x28mm
|
|
Package size
|
180x120x50mm
|
|
Net weight
|
200g
|
|
Shell material
|
ABS
|
