Silicone Rubber Cold Shrink Tube With Mastic Inside

Silicone Rubber Cold Shrink Tube With Mastic Inside is applied for insulation And Sealing For cable splices



Features


Part Number: G-CSTM



Material: Silicone rubber, Mastic



Approval: UL, ROHS, REACH



Working Temperature: -40℃~+200℃



Shore A hardness: 35-45A



Flame Retardant Rating: UL94-V0



Standard Color: Black, Grey, Red, Green, Yellow



Packing: PE Bag and carton







✔ Simple installation, no heat requires.



✔ Seals tight, retains its resiliency and pressure even after long time ageing and exposure.



✔ Waterproof for outdoor use.



Testing Performance



Technical Data Typical Value Test Standard
Tensile Strength / MPa 10.3 ASTM D 421
Elongation at break /% 900% ASTM D 412
Shore A hardness 35-45 GB/T 531.1-2008
Tear Strength N/MM 48.6 ASTM D 624
Volume Resistivity /Ω.m 1.3X1017 ASTM D 4325
Sealing IP67 IEC60529
Dielectric strength 23kv/mm ASTM D 4325
Ozone Resistant Passed ASTM G154-06
UV-resistance Passed ASTM G154-06
Low temp. Resistant -40℃ ISO 812
Flame retardant V-0 UL-94





Specification




As supplied(mm)

Application Range(mm)

After recovered(mm)

P/N

MM

Min

Max

Length

Wall thickness

G-CSTM-18/5

⏀18

5.7

13.0

50~200

2.5

G-CSTM-25/7

⏀25

7.3

21.0

50~300

2.5

G-CSTM-28/9

⏀28

9.0

23.0

50~300

2.5

G-CSTM-30/9

⏀30

9.1

25.0

50~400

2.5

G-CSTM-35/10

⏀35

10.4

30.1

50~400

2.5

G-CSTM-40/11

⏀40

11.7

35.1

50~400

3.0

G-CSTM-45/12

⏀45

12.7

40.0

50~450

3.0

G-CSTM-50/16

⏀50

16.0

45.0

50~450

3.0

G-CSTM-55/18

⏀55

18.2

49.2

90~800

3.0

G-CSTM-60/18

⏀60

18.2

53.0

90~800

3.0

G-CSTM-65/22

⏀65

22.4

58.0

90~800

3.0

G-CSTM-70/22

⏀70

22.4

63.6

90~800

3.0

G-CSTM-75/28

⏀75

28.0

66.0

90~800

3.0

G-CSTM-80/30

⏀80

30.0

72.0

90~800

3.0

G-CSTM-90/33

⏀90

33.0

82.0

90~800

3.0

G-CSTM-100/39

⏀100

39.0

92.0

90~800

3.0




NOTES:

• Special size can be customized by requirement.

• Special color and package can be customized by requirement.

• Detailed specification is available if needed.
