Cabin

Driving type 4*2     LHD

D12 standard cab, with Air Condition,

as attached photo for ref.

Vehicle Main Dimensions

Overall dimensions (L * W * H)mm

4800*2550*3100

Wheel base (mm)

2800

Weight in KGS

Tare Weight

6180

Front axles loading capacity

1x7000

Rear axles loading capacity

1x16000

Engine

Brand

Sinotruk

Model

WD615.62

Type

4-stroke direct injection , 6-cylinder in-line with water cooling, turbo-charging and inter-cooling

Horse Power(HP)

266/2200 rpm

Emission standard

Euro Ⅱ

Gearbox

ZFS6-120, 6 Forwards gear/ 1 reverse gear

Clutch

Reinforced coil spring clutch, diameter 420mm

Steering Gear

EATON

Tire

11.00-20 nylon tyre 7 pcs including one spare tire

Brakes

Service brake.dual circuit compressed air brake

Parking brake emergency brake spring energy, compressed air operating on rear wheels

Auxiliary brake: engine exhaust brake

Fifth wheel

2.0 or 3.5, fixed type
