Best Material

we use the import material, AF,SANDVIK,KENNA,CB,etc


Carbide Rod Grade

Type Material Co Grain size Flexural Strength
HRC45 YG10X(Zhuzhou) 10% 0.7um 3320N/mm2
HRC55 YG10.2&WF25(Taiwan)
10% 0.6um 4000N/mm2
HRC65 H10F(Sweden) 10% 0.5um 4300N/mm2


Coating Grade

Type Hardness(HV) Thickness(UM) Oxidation Temp Friction Coefficient Color
AITiN 3200 2.5-3 900 0.3 Black
TiSiN 3600 3 1000 0.45 Copper
nACo 42(GPA) 3 1200 0.4 Blue



Advanced Equipment

ANCA & DECKEL for producing end mills

PG1000 & PARLEC for detecting


Application

suitable for processing cast iron, copper,carbon steel etc.


Quality

all our manufactured parts are inspected by advanced zoller mearsurement.


Flexbility:

non-standard sizes are accepted.We can supply for you with different types,from the low price to high quality.




Product Description

HRC45 suitable for Iron, Cast Iron, Common Steel under hardness HRC45
HRC55 suitable for Iron, Cast Iron, Common Steel, Hardened Steel under hardness HRC55
HRC65 suitable for Hardened steel; Mold steel; Die steel; Alloy steel above HRC60

Name
Solid Carbide End Mill
Material
Tungsten Carbide
Flutes
2/4/6 Flute
Hardness
HRC45, 55, 65
Helix Angle
30° 35° 45°30° 35° 45°AlTiN, NACO BLUE, NACO BLACK, TiN etc.
Coating
AlTiN, NACO BLUE, NACO BLACK, TiN etc.
HRC45, 55, 60, 65, 68
Flat end mill, ball nose end mill, corner radius end mill and aluminium processing end mill
Size
Dia: 1-20 mm, Overal Length:50-150mm
Smooth Finish
Highly Polished
Feature
Excellent chip evacuation





ZONG



Our Advantage

• ISO 9001-2008 Quality Control System.
• 100% virgin tungsten carbide.
• OEM,ODM project accepted.
• All payment terms supported.
• Fast delivery time & Convenient Transportation.



Packaging & Shipping

Normally 1piece/plastic box. Could be customized with your demands.

We cooperated with the cheapest express shipping company, saving much shipping cost for you




Buyer Feedback






Exhibition



FAQ

Q: Are you trading company or manufacturer ?

A: We are end mill factory.Our factory is located in zhuzhou City, Hunan Province. Welcome to visit our factory!

Q: How long is your delivery time?

A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.

Q: Do you provide samples ? is it free or extra ?

A: No, we could not offer the sample for free, but we can give you a big discount for big order

Q: What is your terms of payment ?

A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
