Superb Tent provides various and adjustable tents for your outdoor events: not just
a simple protection from changing weather, but also a friendly and comfortable space
to build for all types of outdoor promotion, advertising, beer festival, company
celebration, security checking areas, rest rooms for athletes, and other different
sport courts.
Available sizes:
Clear span available from 3m to 60m.
Length: adjustable by 3m unit (SS & WS series) or 5m unit (for other series).
Features:
No exterior guy ropes or staking required.
No poles inside, 100% interior space be used.
Roof and gable vent is available.
Relocatable, easy to install, dismantle and transport.
Full line accessories available.
Cover:
Kedered roof fabric and sidewalls provide weather-proof tight coverings.
Bar tensioning roof & sidewalls system.
Different brand fabric for option: China Fabric, Ferrari, Sioen, Verseidag.
Frame:
No maintenance required.
Extruded 4 channel aluminum hollow profiles with anodized finishing above 12um.
All steel connectors including small parts have galvanized finishing above 60um.
Modular character for diverse combination and expansion.
The Specification of Sport Event Tent：
|
Type
|
Span (m)
|
Side height (m)
|
Ridge height (m)
|
Bay Distance (m)
|
Roof Pitch
|
Longest Component (m)
|
Wind Load (km/h)
|
|
WS6/3-3
|
6
|
3
|
4.1
|
3
|
20°
|
3.5
|
80
|
|
WS9/3-3
|
9
|
3
|
4.6
|
3
|
20°
|
4.9
|
80
|
|
WS10/3-3
|
10
|
3
|
5.1
|
3
|
20°
|
6.5
|
80
|
|
WS15/3-3
|
15
|
3
|
5.6
|
3
|
20°
|
8.1
|
80
|
|
Main frame Profile
|
122x68x3mm（4-channel)
|
|
Eave Connection
|
Hot-dip Galvanized Steel Insert
|
|
Roof Fixing
|
Bar Tension
|
|
Frame Material
|
Hard Pressed Extruded Aluminum 6061/T6
|
|
Cover Material
|
Double PVC coated Polyester textile, flame retardant to DIN4102 B1,M2,650-900g/sq.m
|
