SrTiO3 perovskite crystal structure with a variety of good lattice matching material, which is a variety of high-temperature superconducting oxide thin film and the substrate material quality, but also widely used in special optical window and the highest quality sputtering target timber.HB company has an independent set of production line, from high-quality SrTiO3 powder, SrTiO3 single crystal polished to a variety of sizes epitaxial substrate for high-quality low-cost global provider of monocrystalline and SrTiO3 substrates.
|
Major capability parameter
|
|
Crystal structure
|
M6
|
|
Growth method
|
Blaze method
|
|
Unit cell constant
|
a=3.905Å
|
|
Melt point（℃）
|
2080
|
|
Density（g/cm3）
|
5.122（g/cm3）
|
|
Hardness
|
6-6.5（mohs）
|
|
Thermal expansion（/℃）
|
9.4×10-6
|
|
Dielectric constants
|
ε=5.20
|
|
Chemical stability
|
Insoluble in water
|
|
Tangent loss
|
~5×10-4（300k） ~3×10-4（77k）
|
|
Size
|
10×3m、10×5m、10×10mm、15×15mm、20×15mm
Special size and orientation are available upon request
|
|
Thickness
|
0.5mm、1.0mm
|
|
Size tolerances
|
<±0.1mm
|
|
Thickness tolerances
|
<±0.015mmspecial in<±0.005mm）
|
|
Polishing
|
Single or double
|
|
redirection precision
|
±0.5°
|
|
Redirection the edge:
|
2°（special in 1°）
|
|
Crystal orientation
|
<100>、<110>、<111>
|
|
Pack
|
100 clean bag，1000 exactly clean bag
|
