*High-Performance Lithium Solar Battery
The 51.2V 100Ah/200Ah/280Ah/314Ah LiFePO4 wall-mounted solar lithium battery by Sunrange Energy delivers reliable and efficient energy storage for solar power systems. Built with high energy density and Grade A lithium phosphate cells, it provides exceptional longevity and stability.
*Advanced Battery Management System (BMS)
Equipped with a sophisticated BMS, this battery ensures safety by preventing overcharging, overheating, and short-circuiting. The BMS optimizes efficiency and extends the battery’s lifespan, making it a secure choice for both residential and commercial solar installations.
*Eco-Friendly and Long-Lasting
The battery’s environmentally friendly lithium phosphate chemistry offers a sustainable energy solution. Its long cycle life means less maintenance and fewer replacements, making it a smart investment for renewable energy systems.
*Designed for Versatile Solar Applications
Ideal for home, commercial, or industrial settings, this battery pack serves well in off-grid solar systems, backup power, or grid-tied applications. Its compact design and efficient energy output suit a variety of energy storage needs.
| Model No |
SRW-100-16S |
SRW-200-16S |
SRW-280-16S |
| Nominal Voltage(VDC) |
51.2 |
51.2 |
51.2 |
| Nominal Capacity(AH) |
100 |
200 |
280 |
| Nominal Capacity(WH) |
5120 |
10240 |
14336 |
| Usable Capacity(WH) |
4608 |
9216 |
12902.4 |
| Discharge Voltage(V) |
46 |
46 |
46 |
| Charge Voltage(V) |
56 |
56 |
56 |
Recommend Charge/
Discharge Current(A) |
50 |
100 |
140 |
Max.Charge/Discharge
Current(A) |
100(3S) |
200(3S) |
280(3S) |
| Communication |
RS485/CAN/Bluetooth(Optional) |
RS485/CAN/Bluetooth(Optional) |
RS485/CAN/Bluetooth(Optional) |
| Working Temperature |
0-40℃ |
0-40℃ |
0-40℃ |
| Storage Temperature |
-20-70℃ |
-20-70℃ |
-20-70℃ |
| Humidity |
10%-80% |
10%-80% |
10%-80% |
| Certification |
CE/IEC/UN38.3/MSDS |
CE/IEC/UN38.3/MSDS |
CE/IEC/UN38.3/MSDS |
| Design Life |
10 Years+ |
10 Years+ |
10 Years+ |
| Cycle Life |
≥6000@90%DOD(25±5℃) |
≥6000@90%DOD(25±5℃) |
≥6000@90%DOD(25±5℃) |
| Electrical Design Redundancy |
>20% |
>20% |
>20% |
| Dimension |
440*453*206MM |
440*804*196MM |
631*473*266MM |
| Weight |
52KG |
104KG |
115KG |
Advantage comparing with Lead Acid Battery?
Advantage comparing with Lead Acid Battery?
1. Energy Density
Lithium-lon: Higher energy density,meaning they store more energy for the same weight and sizeLead-Acid: Lower energy density,making them bulkier and heavier for the same energy storage capacity.
2. Cycle Life
Lithium-lon: Much longer cycle life,10+ years designed lifespan, up to 6000 cycles.
3. Efficiency
Lithium-lon: High round-trip efficiency of 90-95%, meaning less energy is lost during charging and discharging.
Lead-Acid: Lower efficiency, around 70-80%, with more energy lost as heat.
4. Depth of Discharge(DOD)
Lithium-lon: Can be discharged up to80-90% of their capacity without significantly reducing lifespan.
Lead-Acid: Typically recommended to discharge only 50% of their capacity to maintain longevity.
Compatible Inverters List
1.Is this battery compatible with my inverter?
Yes, it offers excellent compatibility. The built-in BMS supports RS485 and CAN communication protocols, allowing it to work seamlessly with most major brands of hybrid and off-grid inverters.
2.Is the wall-mounted design safe for home installation?
Absolutely. The battery is CE, IEC, and UN38.3 certified for safety. Its wall-mounted design is secure, space-saving, and specifically engineered for residential indoor use.
3.Can you provide customization options for your products?
Yes, we provide OEM Service for you.
4. May I have a piece of sample to check the quality?
Welcome to place the testing order to check the quality or for testing.
