Thrust Ball Bearings with Casing

Thrust Ball Bearing with Casing Models List - SKET Company




We are a professional supplier and exporter of thrust ball bearing in China. Please find our Thrust Ball Bearing with Casing Models List as below.

Our thrust bearings are stable quality with competitve price, welcome contact us get a quote!

Thrust Ball Bearing with Casing Dimensions(mm)
d D T
25TAG11 25.2 43.5 12
25TAG12 25.2 48.6 16
28TAG12 28.2 51.6 16.8
(28TAG001)


T28S1 28.2 53.2 16.4
30TAG12 30.2 54 17
(30TAG001)


32TAG12 32.2 57 17
35TAG12 35.2 64 19
(35TAG001)


40TAG12 40.2 70.5 20.2
(40TAG001)


47TAG001D 47 78 23
50TAG001 50.2 80 19
TAG45-1 45.2 72 15
T4072RS 40 74.4 21.5
50TAG801 50 75.5 19
T5082RS 50.2 85 19
Y-22-1 22.2 40 12.8
Y-25-3 25.2 45 13.8
Y30-1AB 30.2 54 13.8
198905 25.1 49 16
198707 35 55 13
98906 30.1 53 16
98908 38.2 66 18
5.31 28 56 16
5.32 28.3 51.6 16.5




Clutch Thrust Bearings No. Dimensions(mm)
d D T
9588217C23 85 125.75 24.5
9588214 70 105 22
68808K 40 67 14.7
688911KC23 52.388 84.5 20.7
588911KC23 52.388 84.4 19.2
688811KC23 55 90.5 21.5
TT1087 64.05 90 20
TT1171 57.2 93.7 20
1080(A-2013) 38.1 71.5 17.2
1081(A-2256) 52.388 90 20
1082(A-22011) 52.388 90.5 20.5
1083(A-35244) 42.062 76.2 15.7
1084(A-252633) 57.2 96.5 20
1085(A-252631) 57.2 96.5 20
1086(A-2201-3) 70.5 114.5 22
1087(A-15113) 63.5 104 22
A1511 69.85 114 22
551Z15 75 113 21.3
551Z13 62.3 102 22.2
551Z11 55 93.3 22.7
R201 42.062 78.5 18.7
688711 55 91.5 20.3
588909 45 73 17
