Triac Dimmable Driver White UL ROHS Led 30w Driver Led Panel Driver

SMT-012-030VTSP is 100-277vac 12vdc 30w slim type triac dimmable led driver suit for Canada and USA markerting with 7 years warranty,it's CE,UL, FCC,Class 2, Class p, type HL, RoHS listed,the size is only 260*30*18.5mm which could save many space.


  • Dimming modetriac dimmable
  • Working Modeconstant voltage
  • Output Current2.5amp
  • Output Voltage12vdc
  • Size260*30*18.5mm
  • Input Voltage100-277VAC
  • CertificationCE,UL, FCC,Class 2, Class p, type HL, RoHS

Triac Dimmable Driver White UL ROHS Led 30w Driver Led Panel Driver



The Slim Line series dimmable led driver 30w is UL/cUL listed for use in Canada and USA and covered by 7 year manufacturer limited warranty. These slim led drivers are a compact solution for powering LED’s. Typically smaller, lighter and less expensive than magnetic drivers, an electronic LED driver may be preferred for installations where space is at a premium.



Features:

Output constant voltage type  Input voltage range 100-277VAC

UL, cUL listed, Class 2, Class P, CE, ROHS approval

Built-in PFC function / Efficiency > 80% / PF> 0.99

Dimming range: 0~100% / load:10~100%

Protections:short circuit/over voltage/over heat

IP20 design for indoor dry or damp environment installations

Cooling by free air convection

Work with Forward phase, Reverse phase, Triac, MLV, ELV Dimmers

PWM output, does not change the color index

Plastic housing,IP20 rate for dry or damp location

Strong compatibility, flicker-free dimming

Suitable for LED lighting and moving sign applications

Compliance to worldwide safety regulations for lighting

7 years warranty


RAQ:


Q1. Can I have a sample order for LED Driver?

A: Yes, we welcome sample order to test and check quality. Sample/ Trial order are acceptable.



Q2. What about the lead time?

A: Sample needs 7 days, mass production time needs about 10-12 days. Depends on order quantities.



Q3. Do you have any MOQ limit for LED Driver order?

A: Low MOQ, 1pc for sample checking is available.



Q4. How do you ship the goods and how long does it take to arrive?

A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.



Q5. How to proceed an order for LED Driver?

A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.

Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.



Q6. Is it OK to print my logo on LED Driver product?

A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.



Q7: Do you offer guarantee for the products?

A: Yes, we offer 2-7 years warranty to our products.





Q8: How to deal with the faulty?


A: Firstly, Our products are produced in strict quality control system and the defective rate will be less
than 0.02%.
Secondly, during the guarantee period, we will send new LED Driver with new order for small quantity. For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to real situation.


 Problem analysis:

Queation:What are the details of the 7 year warranty: Is it based on 7 years of actual use? We understand that some driver manufacturers have technology to keep track of hours of use. Or does the warranty start at point of sale and end 7 years after? Please explain details.

Answers:

The 7 years warranty start at the point of LED Driver leave our factory. There have manufacture date in back of every LED driver.

We use the best quality components for our 277vac dimmable series and the capacitances we used have the super life-span. We can promise 7 years warranty if loading 80% and within 12 hours working time per days.
