Why 3601E Matters
The TRICONEX 3601E is a TÜV-certified, SIL-3, 16-point digital output module built for Tricon v10 systems. Each channel sinks 24 VDC @ 2 A, is short-circuit protected, and is galvanically isolated at 1 500 V.
Mean-time-between-failure (MTBF) is rated 312 years at 25 °C, making it the work-horse for ESD, F&G and HIPPS cabinets worldwide.
A single on-board 32-bit CRC checks every output transition; fault data is auto-reported to the Tricon bus in <5 ms. If you need a module that never takes a day off, 3601E is it.
Quick-Spec Table
|
Parameter
|
Value
|
|
Part Number
|
3601E (Enhanced)
|
|
Points
|
16, common negative
|
|
Load voltage
|
24 VDC (18–32 V)
|
|
Max current / pt
|
2 A ( resistive )
|
|
Surge protection
|
1 500 W TVS, 8/20 µs
|
|
Isolation ch-ch
|
500 V rms
|
|
Isolation field-logic
|
1 500 V rms
|
|
On-state drop
|
0.3 V @ 2 A
|
|
Off-state leakage
|
<0.5 mA
|
|
Diagnostic
|
Open-load, short-to-supply, over-temp
|
|
MTBF (MIL-HDBK-217F)
|
312 yrs @ 25 °C
|
|
Safety cert
|
IEC 61508 SIL 3, TÜV Rhineland
|
Drop-in Replacement & Compatibility
3601E is a direct plug-and-play upgrade for legacy 3601A/B/C modules; no re-wiring, no new baseplates. Firmware auto-detects the enhanced ID code and enables the extra diagnostics.
Hot-Selling Triconex
|
Rank
|
Model
|
Description
|
|
1
|
3604E
|
64-point DO, 24 VDC, SIL-3
|
|
2
|
3503E
|
32-point DI, 24 VDC, SIL-3
|
|
3
|
3624
|
6-point AO, 4–20 mA, SIL-3
|
|
4
|
3664
|
8-point AI, 4–20 mA, SIL-3
|
|
5
|
3601E
|
16-point DO, 24 VDC, SIL-3
|
|
6
|
3008
|
Main processor, 2 MB
|
|
7
|
4329
|
Network comm module, Dual Ethernet
|
|
8
|
3700A
|
Power module, 120 VAC/DC, 175 W
|
|
9
|
3721
|
Power module, 24 VDC, 175 W
|
|
10
|
9563-810
|
RXM rack, 21 slots
|
What happens next?
-
-
-
Your quote
You’ll get a fully customized quote to fit your unique needs.
-
