Triconex 4211 Remote Extender Module (RXM)
Email: sales@amikon.cn
Remote Extender Module
(RXM)
RXMs and chassis allow I/O modules
to be located several kilometers from
the Main Chassis. RXM sets, consisting
of three identical modules, serve as
repeaters and extenders of the Tricon
I/O bus and provide ground loop isola-
tion. A primary RXM set supports three
remote locations by connecting to three
remote RXM sets housed in a remote
chassis.
RXM sets are available for fiber-optic
cables with a communication rate of
375 kilobits per second. These sets
provide maximum immunity against
electro-static and electro-magnetic
interference, and support configura-
tions with optical modems and fiber-
optic point-to-point cabling. Remote
sites can be located as far as 7.5 miles
(12 kilometers) from the primary site.
The figure at right shows uni-direc-
tional cabling for three channels of a
remote location. For each channel, one
cable carries data transmitted from the
primary RXM to the remote RXM, and
the other cable carries data received by
the primary RXM from the remote
RXM. A pair of modules must be wired
for each of the three channels,
amounting to a total of six cables for
each remote location.
INFORMATION
|
RXM Model
|
4211
|
|
RXM Chassis Location
|
Remote
|
|
Cable Type
|
Single-mode
|
|
Cable Length Limit
|
7.5 miles (12 kilometers)
|
|
Connectors
|
6
|
|
Remote Sites Supported
|
n/a
|
|
Modem Ports
|
Fiber Optic with ST connectors
|
|
Diagnostic Indicators
|
PASS, FAIL, ACTIVE, TX, RX1, RX2, RX3
|
