TRICONEX 8310 | TRICON 8310 175-Watt Power Module

TRICONEX  8310





TRICONEX  8310 TRICON 8310 175-Watt Power Module


Contact: Sunny Guo

Email:sales2@amikon.cn (click!)
Skype:live:ariatang111 (click!)
Mb(Whatsapp):+86-18020776791
Wechat:18020776791
QQ:2851195478
Tel:86-592-5321698



Isolation

>1,000 VAC or 1,500 VDC, Input to Output

Input Terminations

Protected by safety cover

Accepts three 12-gauge wires (3.310mm2): neutral, hot, and

protective earth (chassis ground)

Over-Temp. Sensor

Temperature warning monitor—trips when internal temp. is

greater than 181° F (83°C); this typically occurs at ambient

temperature 140°F (60°C) or higher

Alarm Contacts

Normally open, normally closed and common

Each contact supports 120 VAC @ 1 amp

Accepts 12-gauge (3.310mm2) wire

Protected by safety cover

Input Power Required

240 watts minimum per Power Module

Output Power 175 watts at 140°F (60°C)

Output Voltage 6.5 VDC, ±1% under all operating conditions

Output Current 27 amps maximum at 140°F (60°C) ambient
