Module Overview
1. Type: Analog Output Module
2. Output Channels: 8 isolated channels
3. Output Range: 4–20 mA DC
4. Redundancy Architecture: Triple Modular Redundancy (TMR)
5. Primary Function: Converts digital control signals into high-precision analog outputs to drive actuators and field devices
Key Highlights:
1. Built-in real-time self-test and channel monitoring
2. Hot-swappable design for uninterrupted operation
3. High accuracy and low-noise output, suitable for SIL 3 systems
4. Stable operation in environments from 0°C to 60°C
|
No.
|
Part number
|
Description
|
Typical host rack
|
Remarks
|
|
1
|
8311 / 8311N
|
24 VDC → 3×TMR power module
|
8110 / 8120 main
|
Today’s focus
|
|
2
|
8110
|
32-slot main chassis
|
—
|
Default left slot for 8311
|
|
3
|
8300A
|
115 VAC/DC power module
|
8110
|
Alternative/redundant option to 8311
|
|
4
|
3008
|
Main processor (TMR)
|
8110
|
Triple CPU
|
|
5
|
3503E
|
24 VDC digital input 32-pt
|
any I/O row
|
SIL-3 DI card
|
|
6
|
3604E
|
24 VDC digital output 16-pt
|
any I/O row
|
SIL-3 DO card
|
|
7
|
3703E
|
Analog input 0-20 mA 16-pt
|
any I/O row
|
4–20 mA / HART
|
|
8
|
3805E
|
Analog output 4-20 mA 16-pt
|
any I/O row
|
Redundant AO
|
|
9
|
4351B
|
Communication module (CM)
|
chassis rear
|
RS-485 / Modbus
|
|
10
|
4508
|
High-speed channel interface (HIM)
|
rear
|
SOE / speed monitor
|
