Product Highlights
1. Two-out-of-three voter – keeps output valid even if one die fails
2. 1 ms SOE time-stamp – find the first-out trip within 0.1 s
3. -40 °C polar proof – working on NW-LNG & Arctic FPSO
4. Hot-swap in 45 s – change the card without shutting down the rack
2. Specs @ a Glance
|
Key data
|
Value
|
Industry bench-mark
|
|
Channels
|
32 DI
|
2× density vs. 16-ch cards
|
|
Input range
|
18-36 VDC
|
accepts 24 V battery float
|
|
Response
|
< 1 ms
|
40 % faster than average
|
|
Isolation
|
1 500 Vrms
|
immune to ground surge
|
|
Power
|
3.2 W
|
runs cool, no extra fan
|
|
Approvals
|
SIL 3 / CE / UL / ATEX opt.
|
global project passport
|
3. Q&A Plaza
Q1: Can 9753-110 share the same rack as legacy 3503E?
A: Yes – fully compatible with V9 & V10, auto-detected by firmware.
Q2: What is the SIL 3 PFDavg for a fire-&-gas loop?
A: 1.03 E-04, giving > 70 % SIL 3 margin.
Q3: Will 12 V signals work?
A: Anything below 15 V is seen as logic 0; choose 3504E-10 for wide-range.
Q4: Do I need redundant power feeds?
A: No – the board triple-takes power from a single 24 V rail.
