The CM2201 7400206-100 is a 32-channel, TÜV-certified SIL-3/Class 1 Div 2 safety digital input module that belongs to the latest Tricon v10 platform. It scans 24 VDC field contacts at <2 ms, performs on-board 2oo3 voting and delivers 100-year MTBF thanks to triple-modular-redundant (TMR) architecture. Ideal for ESD, F&G and high-speed burner-management applications where a single mis-diagnosis is not an option.
Key Benefits
• Triple-islated channels – no common-mode failure path
• Hot-spare insertion – replace without shutting down the Tricon rack
• Built-in line-monitoring – detects short, open and ground leak before the plant knows
• Compatible with existing 7400206-xxx cables & marshalling – zero re-wiring when upgrading from CM3201 or CM4201
|
Parameter
|
Value
|
|
Part Number
|
7400206-100 (also printed on pull-out label)
|
|
Channels
|
32 sinking inputs, grouped 4 × 8
|
|
Voltage Range
|
15–32 VDC on-state, <5 V off-state
|
|
Input Current
|
3.2 mA @ 24 V (typical), 5 mA max
|
|
Scan / SOE Resolution
|
2 ms, 1 ms optional (firmware ≥ v3.4)
|
|
Isolation
|
Channel–bus 500 Vrms, channel–channel 250 Vrms
|
|
SIL / Certification
|
IEC 61508 SIL 3, TÜV Rheinland 968/EZ 720.00/19
|
|
MTBF (IEC 62380)
|
1,050,000 h @ 40 °C; 1,550,000 h @ 25 °C
|
|
Power Dissipation
|
2.8 W module only; 4.2 W max with 32 active inputs
|
|
Connector
|
High-density 50-pin D-Sub, screw-lock, gold-plated
|
|
Weight / Dimensions
|
0.42 kg; 5 HP × 160 × 140 mm (W × H × D)
|
|
Operating Temperature
|
-40 … +70 °C (derating >60 °C, see graph)
|
|
Hazardous Area
|
Class I Div 2 Groups A–D; ATEX Zone 2 II 3 G Ex ec IIC T4 Gc
|
