Product name

Cargo rigid

Type

6×4

Length x Width x Height(mm)

11304×2499×3228

Wheelbase(mm)

5600+1370

Front overhang/Rear overhang(mm)

1460/2874

Top speed(km/h)

117

GVW(kg)

25000

Rated load(kg)

-

Kerb Weight(kg)

9450

Approach/Departure angle(°)

15/9

Cab

Type

Cab-over-engine, Std. roof , single bunk

Passengers(person)

3

Engine

Model

GH1A

Manufacturer

UD Trucks Corporation

Displacement(L)

10.837

Emission

CN4

Type

Inline 6 cylinders, 4 valves, hydro-cooling, turbo with inter-cooling

Power rating(kw)

280

Max net power(kw)

279

Injection technology

Electric unit injector with max injection pressure 200MPa

After treatment

SCR

Clutch

Type

Single disc, dry, pull-type diaphragm clutch

Disc diameter(mm)

420

Gearbox

Model

F9R20A

Type

Mechanical, manual, 12 forward gears + 2 reverse gears

Steering gearbox

Type

Recirculating ball type hydraulic power-assisted steering system

Axle

Load capacity(kg)

Front: 8000/ Rear:26000(tandem)

Rear axle ratio

4.111

Frame

Type

One piece by roll forming

Max section area(mm)

300×90×(8+5)

Suspension

Type

Front parabolic leaf, Rear multi leaf + T-ride, Front/Rear stabilizer

Leaf Qty.

3/11

Tyre

Specification(either one)

12.00R20-14PR

315/80R22.5-16PR

295/80R22.5-16PR
