Product Name: Anti-Metal RFID Tag For Management System, Uhf Anti-metal Rfid Tag
Description
Anti-metal RFID label is a passive smart label, in line with ISO18000-6B electronic label standards, tags with long-range identification and high-speed anti-collision mechanism, can be used in many areas.
Specification
1.Frequency: FCC: 902MHz~928MHz ETSI: 865-868MHz
2.Protocol: ISO/IEC 18000-6C EPC global GEN2 Class1Protocol: ISO/IEC 18000-6C EPC global GEN2 Class1
3.Chip: Alien H3
4.Polarization: Liner polarization
5.Sensitivity: -17dB -19dB
6.Reading range: 8m (EIRP =30dBm)
7.Writing range: 3.5m (EIRP =30dBm)
8.EPC area: 96bits
9.TID area: 64bits
10.TID area: 64bits
11.User area: 512bits
12.Rewriting: >100000times
Our Advantage
• Logistic tracking tag.
• High performance reading range.
• Available in high-yield volume with stable process.
• RoHS compliant.
• Programming and encoding: depending on our production line, we provide this services
which exactly fit customer's programming, or encoding requirements
Application
Asset Management and Equipment Inspection
Warehouse Logistics Management
Production Process Management
Tracking Management
Container Management
Logistics Sorting
Supply Chain Management
