Feature:
◆Stable reading 60cm,
◆Multiple tags reading ability,
◆Support DEMO and SDK, support secondary
development.
Specification:
|
General
parameters
|
|
Protocol:
|
ISO18000-6C Gen 2
|
|
Working frequency:
|
902MHz - 928MHz or 865MHz - 868MHz
|
|
PSAM card:
|
PSAM9600, PSAM38400
|
|
Barcode function(optional):
|
1D Symbol SE955;2D Symbol SE4500
|
|
Wireless communication(optional):
|
WIFI, Mavell standard
|
|
SPE interface
|
|
Bluetooth
|
|
GPS
|
|
GSM/GPRS
|
|
CDMA 2000 3G network
|
|
CPU
|
Samsung S3C2440A, clocked 400MHZØ
|
|
SDRAM memory (low-power MCP)
|
512Mb SDRAM; 32bit data bus; SDRAM clock
|
|
Flash memory (low-power MCP)
|
1Gb SLC NandFlash
|
|
Operating system
|
Microsoft WinCE 5.0
|
|
Touch screen
|
240*320, 65K colors, 3.2 inch QVGA display
|
|
Buttons
|
28 keys(customized)
|
|
User interface
|
USB/Serial port
|
|
Reading range
|
60cm
|
|
Camera
|
30W, 300W optional
|
|
Power supply
|
300mA
|
