Feature:
◆Could
be easily embedded in tablet PC, PAD,
◆Low power: +3.6V~+5.5V
◆High sensitivty and could read more than
50 tags
◆Support RS232 serial communication
interface(3V TTL)
◆Provide SDK and support multiple
development language, making it easy for user to the secondary development
Specification:
|
Working frequency
|
902~928 MHz or 865~868MHz
|
|
Reading distance
|
3m(depends on antenna)
|
|
Working voltage
|
+3.6V~5.5V
|
|
Protocol
|
ISO18000-6C(EPC G2)
|
|
Antenna
|
1*IPEX antenna
|
|
Size
|
65*37*3mm
|
|
Standby current
|
less than 10mA
|
|
Sleeping current
|
less than 300uA
|
|
Max. RF output power
|
0~30dbm(adjustable)
|
|
Working current
|
560mA
|
|
Communication interface
|
TTL-RS232
|
|
Tag signal strength
|
RSSI value
|
|
Storage temperature
|
-40 C ~ +75 C
|
|
Working temperature
|
-20 C ~ +65 C
|
