Use Mercedes Benz Technology WEICHAI engine 340hp & 380hp North Benz Dump Truck
Traction type: 6X4
Driving type: LHD (RHD is optioned)
| Beiben NG80B 2534,2538 type 6x4 dump truck |
| Cab |
middle
length cab, made by full steel material, anti-crash performance can be
ensured by double hollow chamber structure. Inner A/C |
| Kerb weight |
12280kg |
| Gross Vehicle Weight |
25000kg |
| Wheelbase(mm) |
4750+1450 |
| Engine |
Brand:WEICHAI Model:WP10.375 Emission Standard:EUROII |
| Power (kw/hp):276/275 Max torque:1460N·m/1200—1600rpm |
| Type:Diesel Displacement (L):9.726 |
| Transmission |
Brand:FAST GEAR Model:9JS180 9-forward &1-reverse gears |
| Clutch |
Single dry frictional disc,Hydraulic boosting |
| Steering |
Model:ZJ120D |
| Brake |
Service
brake:Brake gap can be adjusted automatically, double circulation air
brake system Assistant brake:Engine exhaust brake Park brake:Potential
springs pressing on middle and rear wheels |
| Frame |
Fish belly shape,variable width, variable section side beam structure |
| Front axle (Use Mercedes Benz Technology) |
7.5 ton non-driving steering axle |
| Middle and Rear axle (use Mercedes Benz Technology) |
13ton strengthened axle, double reduction driving axle with inter-wheel differential and differential lock |
| Tyre |
12.00R20 |
| Fuel tanker capacity (L) |
300 |
