| Type |
Fully-auto tripod turnstile |
Semi-auto tripod turnstile |
| Strong mechanism structure |
The lossless modular mechanism structure independently developed by CMOLO adopts CNC machining technology to ensure the high precision of each module of the mechanism. |
| The mechanism adopts the mechanical structure of secondary transmission. The gear transmission ratio is precise, efficient and stable, which can precisely control the rotation angle of the arm and reduce the loss, ensure the reliability of the mechanism and enhance the service life of the mechanism. |
The mechanism adopts advanced hydraulic buffer, with advanced buffer design structure, which effectively reduces the noise and mechanical vibration, makes the operation more efficient and stable, and reduces the loss, ensures the reliability of the mechanism and enhances the service life of the mechanism. |
| Core control algorithm |
Using advanced servo control system and DSP+ARM motor control technology, combined with the motor control algorithm independently developed by CMOLO, to achieve precise control and positioning of the obstacle. |
The main control center adopts the advanced algorithm based on ARM core, with advanced photoelectric sensors and high-quality solenoids, to achieve efficient and accurate control logic. |
| Arms status monitoring |
The vertical-type anti-tailgating tripod turnstile adopts a closed-loop feedback control system to monitor the movement status of the arm, which can sensitively detect behaviors that threaten the safety of the passageway, such as illegally hitting the arm and reverse passage, and then issue warnings in the form of sound and light, and can be linked with other security systems. |
-- |
| Passing prompt of Automatic rotation |
After the pedestrian provides a legal door opening signal, the arm rotates at a certain angle in the opening direction, indicating that the pedestrian can pass, and then the pedestrian gently pushes the arm, and the arm automatically rotates in the opening direction. |
-- |
| Over-force feedback control |
When the gate is momentarily subjected to an impact force beyond the safe range, the gate can be slowly pushed for a certain distance to buffer the impact force on the mechanism and the reverse impact force on pedestrians. |
-- |
| Prevent reverse passage |
Mechanical electric control locking structure design, anti-illegal hitting arm and reverse passage. |
Mechanical electric control locking structure design, anti-illegal hitting arm and reverse passage. |
| Anti-tailgating |
The vertical-type anti-tailgating tripod turnstile adopts mechanical anti-tailgating design, which can realize only one person passing through at a time. |
| Long service life |
CMOLO's independently developed advanced mechanism structure, equipped with high-quality DC brushless motor (core of the mechanism), so that the mechanism has a long service life. The mechanism and control system of the vertical-type anti-tailgating tripod turnstile have passed 10 million life tests. |
CMOLO's independently developed advanced mechanism structure, equipped with high-quality solenoid (core of the mechanism), so that the mechanism has a long service life. The mechanism and control system of the vertical-type anti-tailgating tripod turnstile have passed 10 million life tests. |
