Technical Data Pack: VIBRO-METER VM600 MPC4 200-510-070-113
Product Identity
VM600 MPC4 (PN 200-510-070-113) is a compact machinery protection controller that combines four universal dynamic-input channels, two speed/tachometer channels, and a dual-core ARM Cortex-A9 DSP on a single 3U card. It delivers SIL-2 certified protection logic for vibration, speed, and process variables in rotating machinery .
Core Specifications
|
Parameter
|
Value
|
|
Dynamic Inputs
|
4 (acceleration, velocity, displacement, dynamic pressure)
|
|
Tachometer Inputs
|
2 (phase & speed)
|
|
Sampling Rate
|
50 kHz per channel
|
|
Scan Cycle
|
Deterministic 2 ms
|
|
Memory
|
1 GB DDR3, 8 GB eMMC
|
|
Communications
|
2 × 1 GbE (EtherNet/IP, Modbus TCP), RS-485, USB 2.0
|
|
Safety Rating
|
SIL 2 (IEC 61508)
|
|
Power
|
24 V DC ±20 %, redundant terminals
|
|
Operating Temp
|
–40 °C … +70 °C
|
|
Housing
|
IP66 front, IP20 rear, fanless
|
|
Dimensions
|
163 × 38 × 58 mm, 0.35 kg
|
Key Features
• All-in-one card: signal conditioning, protection logic, and network gateway in one slot
• Real-time DSP: FFT, phase analysis, order tracking, envelope demodulation
• Hot-swap: card can be inserted/removed live without rack shutdown
• Front BNCs: direct access to raw signals for portable analyzers
• 7 LEDs: STATUS, ALERT, DANGER, OK, TX/RX, POWER, FAULT
Typical Applications
• Gas & steam turbine bearing monitoring
• Centrifugal compressor surge protection
• Pipeline booster station pump diagnostics
• Marine engine crankshaft deflection tracking
Related VM600 Hardware
|
Part Number
|
Description
|
|
200-510-070-113
|
MPC4 controller (this unit)
|
|
200-510-111-034
|
IOC4T 8-channel temperature / 4–20 mA card
|
|
200-560-000-111
|
IOC4T universal vibration card
|
|
200-566-000-113
|
IOCN vibration/speed card
|
|
200-582-500-013
|
RPS6U 24 V DC redundant power supply
|
|
200-570-000-014
|
RLC16 relay output card (16 SPDT)
|
|
200-595-100-032
|
CPUM central processing module
|
All items are factory-sealed and in stock for same-day dispatch.
