Model	1500 rmp/400v 3P 4W/50HZ/0.8PF				Engine Type	Dimensions(LxWxH)&Weight				DOWNLOAD
	Prime Power		Standby Power			Open Genset		Silent Genset
	KVA	KW	KVA	KW		Dimension(mm)	weight(kg)	Dimension(mm)	weight(kg)
VW-85T5	85	68	94	75	TD530GE	1900*780*1300	1050	3000*1100*1900	1650
VW-85T5	85	68	94	75	TD550GE	2010*900*1550	1150	3000*1380*2050	1750
VW-100T5	100	80	110	88	TAD531GE	2450*780*1610	1226	3500*1380*2050	2147
VW-100T5	100	80	110	88	TAD551GE	2010*900*1550	1150	3000*1380*2050	1750
VW-130T5	130	104	143	114	TAD532GE	2900*900*1610	1335	3500*1380*2050	2233
VW-130T5	130	104	143	114	TAD750GE	2450*900*1610	1620	3500*1380*2050	2200
VW-150T5	150	120	166	133	TAD731GE	2900*900*1610	1571	3500*1380*2050	2469
VW-150T5	150	120	165	132	TAD751GE	2450*900*1610	1620	3500*1380*2050	2200
VW-180T5	180	144	200	160	TAD752GE	2550*1160*1670	1860	3500*1380*2050	2800
VW-188T5	188	150	206	165	TAD732GE	3000*1160*1775	1971	4000*1380*2150	3209
VW-200T5	200	160	220	176	TAD733GE	3000*1160*1775	2017	4000*1380*2150	3255
VW-200T5	200	160	224	179	TAD753GE	2550*1160*1670	1860	3500*1380*2050	2800
VW-245T5	245	196	270	216	TAD734GE	3000*1160*1775	2313	4000*1380*2150	3551
VW-250T5	250	200	275	220	TAD754GE	2650*1160*1670	1970	3500*1380*2050	2900

Model	1800 rmp/480v 3P 4W/60HZ/0.8PF				Engine Type	Dimensions(LxWxH)&Weight				DOWNLOAD
	Prime Power		Standby Power			Open Genset		Silent Genset
	KVA	KW	KVA	KW		Dimension(mm)	weight(kg)	Dimension(mm)	weight(kg)
VW-88T6	88	70	96	77	TD530GE	1900*780*1300	1050	3000*1100*1900	1650
VW-94T6	94	75	106	85	TAD550GE	2050*900*1550	1160	3000*1380*2050	1760
VW-105T6	105	84	110	88	TAD531GE	2450*780*1610	1226	3500*1380*2050	2147
VW-113T6	113	90	126	101	TAD551GE	2050*900*1550	1220	3000*1380*2050	1830
VW-133T6	133	106	146	117	TAD532GE	2900*900*1610	1335	3500*1380*2050	2233
VW-145T6	145	116	168	134	TAD750GE	2480*900*1610	1650	3500*1380*2050	2230
VW-163T6	163	130	179	143	TAD731GE	2900*900*1610	1571	3500*1380*2050	2469
VW-173T6	173	138	191	153	TAD751GE	2480*900*1610	1720	3500*1380*2050	2300
VW-205T6	205	164	225	180	TAD752GE	2550*1160*1670	1860	3500*1380*2050	2800
VW-206T6	206	165	227	182	TAD732GE	3000*1160*1775	1971	4000*1380*2150	3209
VW-220T6	220	176	242	194	TAD733GE	3000*1160*1775	2017	4000*1380*2150	3255
VW-220T6	220	176	242	194	TAD753GE	2550*1160*1670	1860	3500*1380*2050	2800
VW-250T6	250	200	275	220	TAD734GE	3000*1160*1775	2313	4000*1380*2150	3551
VW-250T6	250	200	280	224	TAD754GE	3310*1390*1830	2971	4360*1700*2300	4331

After-sales service

Installation instructions
After the customer receives the goods, GTL can provide online real-time installation and debugging consultation and guidance, or provide the following services if necessary:
1. Assign engineering and technical personnel with installation experience to the site for installation guidance.
2. Assign skilled technicians with debugging experience to the site to carry out equipment debugging and trial operation together with the engineering and technical personnel of the customer, and submit the test data report.
Training
If customers have needs, our company will arrange technical personnel for training and guidance. Our company can provide factory training, video online training and on-site training for users to choose.
Maintenance services
No matter where your crew is, you can get our professional technical advice and services. GTL will set up customer files for each customer and provide regular inspection service. It can also make maintenance plans for customers and provide corresponding spare parts.

Part of the Case
