VS-S720-10G-3C Overview
Cisco Catalyst 6500 Series Virtual Switch supervisor engine VS-S720-10G-3C combines 2 * X2-base 10 Gigabit Ethernet uplinks and hardwarebased layer2-4 switching feature set which enables enriched Layer 3 routing, MPLS, VPNs, QoS and security features. The combination enables
high availability, operational efficiency and increased throughput with scalable performance with ease of deployment.
VS-S720-10G-3C Speicification
|
Product
Description
|
Catalyst 6500
Supervisor engine 720-10G-VSS (PFC 3C)
|
|
Devide Tyde
|
Control
Processo
|
|
Ports
|
2
* 10G X2, 2 * 1G SFP, 1 * 10/100/1000 GE
|
|
Console ports
|
RS-232
|
|
Centralized switching capacity
|
720
Gbps
|
|
Per-slot switching capacity
|
40
Gbps
|
|
Compatibility
|
●
Cisco 6500 Catalyst Series
● Cisco 7600 Catalyst Series
|
|
FNF (Flexible NetFlow) entries
|
128000
|
|
Forn Factor
|
Plug-in
Module
|
|
Memory
|
●WS-SUP720
supports 512MB of DRAM for the route processor and 512 MB for the switch
processor
●64MB or 512MB (s/w image dependent) Boot Flash for SP switch processor and
64-MB of Boot Flash for the route processor
|
|
Options
|
Removable
storage: 64MB, 128 MB, 256 MB, 512 MB (Compact Flash)
|
|
Throughput (in hardware)
|
●
450 Mpps for IPv4
● 225 Mpps for IPv6
● 450Mpps for Layer 2 Bridging
|
|
Routing entries
|
●
IPV4: 256,000
● IPV6: 128,000
|
|
NetFlow Entries
|
128000
|
|
Security ACL entries
|
32000
|
|
Number of interfaces with unique ACLs
|
512
|
|
MAC ACLs on IP
|
No
|
|
Aggregate Traffic Rate-Limiting Policers
|
1023
|
|
NAT
|
Hardware
assisted
|
|
DRAM
|
●
MEM-S3-1GB: Catalyst 6500 1GB SP DRAM for Sup720 and Sup720-3B
● MEM-MSFC2-512MB: Catalyst 6500 512MB DRAM on the MSFC2 or SUP720 MSFC3
|
