Main Features
-
Maximun Voltage&Current:1000V maximun pressure, 30A maximun operation current,copper tin-plated conductive core, oxidation resistance, good conductivity.
-
Solar Panel Connectors: PV connectors are designed for connect solar panels arrays,usually in parallel applications.The adaptor is also specially designed to connect photovoltaic solar systems with high mechanical requirements and extreme weather conditions.
-
Waterproof & Anti-Oxidation Connector: The shell is made of pro insulating &hard plastic material with high rigidity,high heat resistance,fire resistance,wear resistance,pollution resistance,excellent aging resistance and anti-ultraviolet ray ability,and can resist severe weather such as heavy rain,snowstorm or heat for a long time.
Specification
|
Insulation Material:
|
PPO
|
Contact material:
|
Copper,Tin plated
|
|
Rated current:
|
30A
|
Insertion force:
|
Max. 50N
|
|
Rated Voltage:
|
1000V DC
|
Withdrawal force:
|
Min. 50N
|
|
Test voltage:
|
DC6000V
|
Ambient temperature range:
|
-40℃~+125℃
|
|
Contact resistance:
|
1mmΩ
|
Flame class:
|
UL94-V0
|
|
Waterproof protection:
|
IP67
|
Connecting system:
|
Crimping connection
|
|
Overvoltage degree:
|
CATIII/2
|
Suitable cable cross section:
|
2.5/4mm
|
