Waterproof Solar Car Parking Solar BIPV Mount double Column Solar Carport

   According to different demand on the carport size and design, We have single sided carport and double sided carports,The carports can be made of Aluminum or Galvanized steel.. The inclination is 0~15 degrees. The high strength material enables the span between each pillars to be more than 6 meters and can hold 2 cars . The pillars insert into the cement makes the carport structure a good stability.

Feature:
Installation site: Ground
Material:  HDG steel, Anodized Aluminum
Foundation: Concrete foundation, Rammed post
Tilt angle: 0~15degrees
Panel array: Landscape or Portrait
Wind load: Up to 60m/s
Snow load: Up to 2.0KN/M2
Standards: ASCE7-10; EN 1990:2002/A1:2005 Eurocode;AS 1170
Warranty: 12years

This system adopts high-strength carbon steel material photovoltaic bracket, and the surface is treated with high-quality hot-dip galvanizing, which has strong corrosion resistance and is suitable for various natural environments. The system adopts a modular design to provide single parking spaces, double parking spaces, and even rows of parking spaces, which are easy to adjust.

Benefit:
Flexible and Stable
With the adjustable design, maximally absorbs the size error caused by the construction, and guarantees the stability and beauty of the solar mounting structure.
Superb Quality
All raw materials of components are made of carbon steel and aluminum (anodized 6005-T5), which reach the maximum degree of product's weather resistance and the stability of the structure
Easy Installation
The pre-assembled design of the highest level in factory simplifies construction site work to the largest degree and therefore installation is simple and quick. It can effectively improve construction efficiency, shorten construction period and reduce construction costs.
Extraordinarily Environment-friendly Performance
All materials can be 100% recycled, and no waste is generated, which fully embodies the concept of energy saving and environmental protection of the solar photovoltaic power generating system.
