1.High reliability,long lifespan and easy to control.
2. The pixel density is up to 65536 pixel per S.Q.meter. As the small pixel,it can display the picture more clearer.
3. No mosaic due to excellent flatness and nice uniformity of light-emitting,making the images softer and vivider.
4. Wide viewing angles and the horizontal angle can reach 120° the images effect will not Change largely in the range.
5.Exceptional Noise-Free Design
The panels have automatic heat dissipation technology that doesn’t use fans, ensuring noise-free displays with low power consumption.
Technical Specification:
|
Part Number
|
I-P3.9
|
I-P4.81
|
I-P5.2
|
I-P5.95
|
|
Pixel Pitch
|
3.91mm
|
4.81mm
|
5.21mm
|
5.95mm
|
|
Pixel Density
|
65536dot/m2
|
43264dot/m2
|
36864dot/m2
|
28224dot/m2
|
|
Resolution
|
128x128dot
|
104x104dot
|
96x96dot
|
84x84dot
|
|
LED Configuration
|
SMD 2121
|
SMD 3528
|
|
Brightness
|
900-1200CD/m2
|
900-1200CD/m2
|
1500-2000CD/m2
|
1100-1400CD/m2
|
|
View Distance
|
＞4m
|
＞5m
|
＞5m
|
＞6m
|
|
Scanning Mode
|
1/16
|
1/13
|
1/8
|
1/8
|
|
Display Scale
|
16.7M
|
16.7M
|
16.7M
|
16.7M
|
|
Max.Power Consumption
|
600W/m²
|
600W/m²
|
500 W/m²
|
450 W/m²
|
|
Ave.Power Consumption
|
300 W/m²
|
300 W/m²
|
250 W/m²
|
225 W/m²
|
|
Refresh Frequency
|
≥2000HZ
|
≥2000HZ
|
≥2000HZ
|
≥2000HZ
|
|
Cabinet Size
|
500mmx500mmX80mm
|
|
Cabinet Weight
|
8kg
|
|
IP Rating
|
IP43
|
|
Viewing Angle (H/V)
|
140°/120°
|
|
Gray Scale
|
14-16bit
|
|
Brightness Adjustment
|
8 levels adjustable
|
|
Gamma Correction
|
-5.0~+5.0
|
|
Environmental
|
INDOOR
|
|
Control Mode
|
Synchronous display with control PC by DVI
|
|
Support Input
|
Composite,S-Video,Component,VGA,DVI,HDMI,HD_SDI
|
|
Operation Power
|
AC100~240 50/60HZ
|
|
Operating Temperature
|
- 20℃~+50℃
|
|
Operating Humidity
|
10~95% RH
|
|
Operating Life
|
≥50,000hours
|
FAQ
Q1: What's the pixel pitch for Indoor LED Display Screen ?
A1: Indoor&Outdoor 3.9mm/4.8MM/5.2MM/p5.95MM)
Q2: Where is it used for?
A2: Indoor & Outdoor rental use. Widely used for backdrop of staging event, rental business, liveshow, concert, etc.
Q3: Can it play HD video?
A3: Yes, it can realize HD video function with Novastar controlling system.
Q4: What's the controlling system?
A4: Our standard controlling system for this model is Novastar. Also support other controlling system, like Linsn, etc.
Q5: How about the size of project?
A5: Please offer the size with "width by height" of project. We wil offer the suitable solution for your project size. I will appreciate it if any drawing files about installation offered.
