Part A : Features
1)High definition and high brightness;
2)Long durability and high reliability;
3)Advance video control system and Super input system;
4)Low maintenance cost ;
5)Vividly display;
6)Wide viewing angle;
7)Easy installation and maintenance;
Part B: Warranty
1.We guarantee all our display, modules, spare parts (Silan Chip) for TWO years.
2.We provide technology training for free, which contains the operation and maintenance training of the LED screens in factory.
3.After warranty , we also can offer you the parts for replacement at our bottom price.
4.After sales, if you have any problem about our product, you can inform us by Email, we will reply you at once when we get it
and offer you a good solution to solve the problem.
5.We also could solve problems for you until it recovers well by remote control!
Part C: Delivery Time:
1.Delivery time: Accomplish manufacturing within 25 days after receiving the deposit.
2.Before delivery, we will test the display, and keep it light up for 72 hours, and check all the parts of
the display to confirm it is Ok for delivery.
Part D : Installation :
1.We can assist the training and technical support for the customer in the factory, if the customer requires so.
2.We could send our engineer to guide the installation for you. But the relevant cost should be paid by your esteemed company.
3.Our technicians will offer CAD Drawing to show how to install the LED Display rightly and fast, of course, if you need.
Part E :Specification
|
configure
|
Specification
|
Parameter
|
|
Pixel
|
Dot Pitch
|
10mm
|
|
Pixel Configure
|
1R1G1B
|
|
Pixel/SQM
|
10000Pixel/m²
|
|
LED Lamp
|
LED TYPE
|
DIP346
|
|
Chip Brand
|
EPISTAR
|
|
Wavelength & Brightness
|
Red:620-622.5nm;>900mcdGreen:520-522.5nm;>1800mcd
Blue:465-467.5nm;>300mcd
|
|
Module
|
Module Resolution
|
16Pixel * 16Pixel
|
|
Drive Mode
|
Constant Current Drive
|
|
Scanning Method
|
1/4Scanning
|
|
Module Dimension
|
160mm(Width)x160mm(Height)
|
|
Drive IC
|
MBI5024(Or other Similar IC)
|
|
LED & Drive Composition
|
Light-Drive Separation
|
|
Refresh Rate
|
>2400HZ
|
|
Cabinet
|
Cabinet Thickness
|
79.5mm
|
|
Cabinet Construction
|
Normal Standard Cabinet
|
|
Cabinet Assembly
|
Connecting Sheet
|
|
Cabinet Color(Front/Back)
|
Anodized Blue
|
|
Aviation Plug
|
wp20
|
|
Maintenance Mode
|
Back Maintenance
|
|
Cabinet Material
|
Aluminium
|
|
Cabinet Dimension
|
640X640X79.5mm
|
|
Power Supply
|
China Power Supply
|
|
LED Screen
|
Viewing Angle
|
Horizontal : 110±10° Vertical: 60±10°
|
|
Brightness
|
>7500cd/m²
|
|
Best Viewing Distance
|
10~50m
|
|
LED Life
|
100,000Hours
|
|
Maximum Power
|
750w/m²
|
|
Average Power
|
300w/m²
|
|
Input Voltage
|
220V±10% Or 110V±10%
|
|
Operation Environment
|
Temperature: -20°C~60°C; Humidity: 10%~95%
|
|
Protection Grade
|
IP 65
|
|
LED Screen Weight
|
38kg/m2
|
