Subtype
|
Gigabit Ethernet
|
|
Ports
|
24 x 10/100/1000 + 4 x SFP
|
|
Jumbo Frame Support
|
9198 bytes
|
|
Authentication Method
|
RADIUS, Secure Shell (SSH), TACACS+
|
|
RAM
|
4 GB
|
|
MAC Address Table Size
|
32000 entries
|
|
Authentication Method
|
Secure Shell (SSH), RADIUS, TACACS+
|
|
Status Indicators
|
Port transmission speed, port duplex
mode, system, active, status
|
|
Routing Protocol
|
Static IP routing
|
|
Jumbo Frame Support
|
9198 bytes
|
|
Manufacturer
|
Cisco
|
|
NETWORKING
|
|
|
MAC Address Table Size
|
32000 entries
|
|
Subcategory
|
network hubs and switches
|
|
Subtype
|
Gigabit Ethernet
|
|
Form Factor
|
desktop, rack-mountable
|
|
Type
|
Switch
|
|
Stackable
|
stackable
|
|
Features
|
ARP support, Access Control List (ACL)
support, DHCP snooping, Dynamic ARP Inspection (DAI), Energy Efficient
Ethernet, IGMP snooping, Link Aggregation Control Protocol (LACP), MLD
snooping, Multiple Spanning Tree Protocol (MSTP) support, Port Aggregation
Protocol (PAgP) support, Quality of Service (QoS), RADIUS support, Rapid
Per-VLAN Spanning Tree Plus (PVRST+), Rapid Spanning Tree Protocol (RSTP)
support, Remote Switch Port Analyzer (RSPAN), Uni-Directional Link Detection
(UDLD), VLAN support, layer 2 switching, trunking
|
|
Compliant Standards
|
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab
(LLDP), IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE
802.3ab, IEEE 802.3ad (LACP), IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
|
|
Jumbo Frame Support
|
9198 bytes
|
|
Ports Qty
|
24
|
|
Manageable
|
Yes
|
|
Routing Protocol
|
static IP routing
|
|
Remote Management Protocol
|
CLI, RMON 1, RMON 2, RMON 3, RMON 9, SNMP
1, SNMP 2c, SNMP 3, SSH, Telnet
|
|
POWER DEVICE
|
|
|
Power Provided
|
250 Watt
|
|
Nominal Voltage
|
AC 120/230 V
|
|
Frequency Required
|
50/60 Hz
|
|
Type
|
internal power supply
|
|
Hot-Plug
|
hot-plug
|
|
CAMERA
|
|
|
Installed Size
|
2 GB
|
|
POWER
|
|
|
Power Redundancy
|
optional
|
|
Power Redundancy Scheme
|
1+1 (with optional power supply)
|
|
Max Supported Qty
|
2
|
