Capacity
|
|
|
Type
|
Switched virtual
interfaces (SVIs)
|
|
Value
|
1000
|
|
Dimensions
& Weight
|
|
|
Width
|
17.5 in
|
|
Depth
|
19.2 in
|
|
Height
|
1.8 in
|
|
Weight
|
17.64 lbs
|
|
Environmental
Parameters
|
|
|
Min Operating
Temperature
|
23 °F
|
|
Max Operating
Temperature
|
113 °F
|
|
Humidity Range
Operating
|
10 - 95%
(non-condensing)
|
|
Min Storage
Temperature
|
-40 °F
|
|
Max Storage
Temperature
|
158 °F
|
|
Flash Memory
|
|
|
Installed Size
|
2 GB
|
|
Header
|
|
|
Compatibility
|
PC
|
|
Manufacturer
|
Cisco
|
|
Packaged
Quantity
|
1
|
|
Product Line
|
Cisco Catalyst
|
|
Model
|
3850-48U-L
|
|
Brand
|
Cisco
|
|
Interface
Provided
|
|
|
Qty
|
36
|
|
Type
|
Management (mini-USB)
|
|
Connector Type
|
Type B
|
|
Comments
|
Management
|
|
PoE Power
|
60 W
|
|
Miscellaneous
|
|
|
Compliant
Standards
|
Wired/Wireless
|
|
Authentication
Method
|
Kerberos, RADIUS,
Secure Shell (SSH), TACACS+
|
|
MTBF
|
202,030 hours
|
|
Height (Rack
Units)
|
1
|
|
Color Category
|
Gray
|
|
Networking
|
|
|
Type
|
Switch
|
|
Connectivity
Technology
|
Wired/Wireless
|
|
Remote
Management Protocol
|
CLI, RMON 1, RMON 2,
SNMP 1, SNMP 2c, SNMP 3, SSH, Telnet
|
|
Status
Indicators
|
PoE, Port duplex
mode, Port transmission speed, Status, System
|
|
Ports Qty
|
48
|
|
Features
|
Access
Control List (ACL) support, ARP support, Auto-negotiation, Auto-uplink (auto
MDI/MDI-X), Cisco StackPower technology, Cisco StackWise-480 technology, DHCP
snooping, Dynamic ARP Inspection (DAI), Dynamic Trunking Protocol (DTP)
support, Energy Efficient Ethernet, Flexible NetFlow (FNF), IGMP snooping,
IPv4 support, IPv6 support, Layer 3 load balancing, Link Aggregation Control
Protocol (LACP), MLD snooping, Multiple Spanning Tree Protocol (MSTP)
support, Port Aggregation Protocol (PAgP) support, Quality of Service (QoS),
RADIUS support, Rapid Per-VLAN Spanning Tree Plus (PVRST+), Rapid Spanning
Tree Protocol (RSTP) support, Remote Switch Port Analyzer (RSPAN), Shaped
Round Robin (SRR), STP Root Guard, Syslog support, Trivial File Transfer
Protocol (TFTP) support, Trunking, Uni-Directional Link Detection (UDLD),
Virtual Route Forwarding-Lite (VRF-Lite), VLAN support
|
|
Routing
Protocol
|
EIGRP, RIP-1, RIP-2,
RIPng
|
|
MAC Address
Table Size
|
32000 entries
|
|
Stackable
|
Stackable
|
|
Subcategory
|
Network hubs and
switches
|
|
Power Over
Ethernet (PoE)
|
UPOE
|
|
Advanced
Switching
|
Layer 3
|
|
Manageable
|
Yes
|
|
Form Factor
|
Desktop,
Rack-mountable
|
|
Jumbo Frame
Support
|
9198 bytes
|
|
Subtype
|
Gigabit Ethernet
|
|
PoE Budget
|
630 W
|
|
Performance
|
|
|
Type
|
Switching capacity
|
|
Value
|
176 Gbps
|
|
Ports
|
|
|
Qty
|
48
|
|
Type
|
10/100/1000 (UPOE)
|
|
Power Device
|
|
|
Frequency
Required
|
50/60 Hz
|
|
Power Provided
|
1100 Watt
|
|
Installed Qty
|
1
|
|
Max Supported
Qty
|
2
|
|
Nominal
Voltage
|
AC 120/230 V
|
|
Power
Redundancy
|
Optional
|
|
Power
Redundancy Scheme
|
1+1 (with optional
power supply)
|
|
Type
|
Internal power supply
|
|
RAM
|
|
|
Installed Size
|
4 GB
|
|
Service
|
|
|
Support
Details Type
|
Technical support
|
|
Support
Details Service Included
|
Consulting
|
|
Support
Details Full Contract Period
|
90 days
|
|
Service &
Support
|
|
|
Type
|
Limited lifetime
warranty
|
|
Service &
Support Details
|
|
|
Response Time
|
Next business day
|
|
Slot Provided
|
|
|
Type
|
Expansion slot
|
|
Total Qty
|
1
|
|
Free Qty
|
1
|
|
Software
|
|
|
Type
|
Cisco IOS LAN Base
|
