WS-C3850-48T-S Cisco Catalyst 3850 48 Port Data IP Base

The Cisco Catalyst 3850 series is the enterprise-class stackable access-layer switches that provide full convergence between wired and wireless on a single platform.



WS-C3850-48T-S Overview


The Cisco Catalyst 3850 series is the enterprise-class stackable access-layer switches that provide full convergence between wired and wireless on a single platform. Cisco Unified Access Data Plane (UADP) application-specific integrated circuit (ASIC) powers the switch and enables uniform wired-wireless policy enforcement, application visibility, flexibility and application optimization.


WS-C3850-48T-S Specifcation


Environmental Parameters
Min Operating Temperature 23 °F
Max Operating Temperature 113 °F
Humidity Range Operating 10 - 95% (non-condensing)
Min Storage Temperature -40 °F
Max Storage Temperature 158 °F
Header
Compatibility PC
Manufacturer Cisco Systems
Packaged Quantity 1
Product Line Cisco Catalyst
Model 3850-48T-S
Brand Cisco
Interface Provided
Qty 48
Type Management (mini-USB)
Connector Type Type B
Comments Management
Miscellaneous
Compliant Standards BSMI CNS 13438 Class A, CISPR 22 Class A, CISPR 24, CSA C22.2 No. 60950-1 Second Edition, EN 60950-1 Second Edition, EN 61000-3-2, EN 61000-3-3, EN55022 Class A, EN55024, FCC Part 15 A, GOST, ICES-003 Class A, IEC 60950-1 Second Edition, ISO 7779, KCC, NOM, RoHS, UL 60950-1 Second Edition, VCCI Class A
Authentication Method Kerberos, RADIUS, Secure Shell (SSH), TACACS+
MTBF 303,660 hours
Height (Rack Units) 1
Color Category Black, Gray
Networking
Type Switch
Connectivity Technology Wired/Wireless
Remote Management Protocol CLI, RMON 1, RMON 2, SNMP 1, SNMP 2c, SNMP 3, SSH, Telnet
Compliant Standards IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Status Indicators Port duplex mode, Port transmission speed, Status, System
Ports Qty 48
Features Access Control List (ACL) support, ARP support, Auto-negotiation, Auto-uplink (auto MDI/MDI-X), Cisco StackPower technology, Cisco StackWise-480 technology, DHCP snooping, Dynamic ARP Inspection (DAI), Dynamic Trunking Protocol (DTP) support, Energy Efficient Ethernet, Flexible NetFlow (FNF), IGMP snooping, IPv4 support, IPv6 support, Layer 3 load balancing, Link Aggregation Control Protocol (LACP), MLD snooping, Multiple Spanning Tree Protocol (MSTP) support, Port Aggregation Protocol (PAgP) support, Quality of Service (QoS), RADIUS support, Rapid Per-VLAN Spanning Tree Plus (PVRST+), Rapid Spanning Tree Protocol (RSTP) support, Remote Switch Port Analyzer (RSPAN), Shaped Round Robin (SRR), STP Root Guard, Syslog support, Trivial File Transfer Protocol (TFTP) support, Trunking, Uni-Directional Link Detection (UDLD), Virtual Route Forwarding-Lite (VRF-Lite), VLAN support
Routing Protocol EIGRP, RIP-1, RIP-2, RIPng
MAC Address Table Size 32000 entries
Stackable Stackable
Subcategory Network hubs and switches
Power Over Ethernet (PoE) No
Advanced Switching Layer 3
Manageable Yes
Form Factor Desktop, Rack-mountable
Jumbo Frame Support 9198 bytes
Subtype Gigabit Ethernet
Power Device
Frequency Required 50/60 Hz
Power Provided 350 Watt
Installed Qty 1
Max Supported Qty 2
Nominal Voltage AC 120/230 V
Power Redundancy Optional
Power Redundancy Scheme 1+1 (with optional power supply)
Type Internal power supply
Service
Support Details Type Technical support
Support Details Service Included Consulting
Support Details Full Contract Period 90 days
Service & Support Details
Response Time Next business day
Slot Provided
Type Expansion slot
Total Qty 1
Free Qty 1
Software
Type Cisco IOS IP Base
Dimensions & Weight
Width 17.5 in
Depth 17.7 in
Height 1.8 in
Weight 16.98 lbs
Service & Support
Type Limited lifetime warranty
Capacity
Type Switched virtual interfaces (SVIs)
Value 1000
Flash Memory
Installed Size 2 GB
Performance
Type Switching capacity
Value 176 Gbps
Ports
Qty 48
Type 10/100/1000
RAM
Installed Size 4 GB
