Technical
Specifications
|
|
|
General
|
|
|
Device Type
|
Switch
- 48 ports - L3 - managed
|
|
Enclosure Type
|
Rack-mountable
1U
|
|
Subtype
|
Gigabit
Ethernet
|
|
Ports
|
48
x 10/100/1000 + 4 x shared SFP
|
|
MAC Address Table Size
|
32K
entries
|
|
Routing Protocol
|
RIP-1,
RIP-2, EIGRP, static IP routing
|
|
Remote Management Protocol
|
SNMP
1, SNMP 2, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, HTTPS
|
|
Authentication Method
|
Secure
Shell (SSH), RADIUS, TACACS+, Secure Shell v.2 (SSH2)
|
|
Features
|
Layer
3 switching, layer 2 switching, auto-sensing per device, DHCP support,
auto-negotiation, ARP support, trunking, Cisco Fast EtherChannel, VLAN
support, Cisco Gigabit EtherChannel, IGMP snooping, Syslog support,
manageable, MAC address filtering, Broadcast Storm Control
|
|
Compliant Standards
|
IEEE
802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE
802.1p, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s
|
|
Processor
|
1:
266 MHz
|
|
RAM
|
256
MB SDRAM
|
|
Flash Memory
|
64
MB flash
|
|
Status Indicators
|
Power,
link OK, system, status, link/activity
|
|
Expansion /
Connectivity
|
|
|
Interfaces
|
48
x 1000Base-T RJ-45 ¦ 1 x 100Base-TX RJ-45 management ¦ 1 x console RJ-45
management ¦ 4 x SFP (mini-GBIC)
|
|
Power
|
|
|
Power Device
|
Internal
power supply - hot-plug
|
|
Installed Qty
|
1
(installed) / 2 (max)
|
|
Power Redundancy
|
Yes
|
|
Voltage Required
|
AC
120/230 V (50/60 Hz)
|
|
Miscellaneous
|
|
|
Compliant Standards
|
NEBS
level 3, ETSI, CISPR 22 Class A, EN 60950, EN 61000-3-2, IEC 825-1/EN 60825-1
class 1, VCCI Class A ITE, IEC 60950, EN 61000-3-3, EN55024, EN55022 Class A,
UL 60950, EN50082-1, CSA 22.2 No. 60950, AS/NZS 60950-1, FCC Part 15,
ICES-003 Class A, AS/NZS 3548
|
|
Pricing Type
|
Refurbished
|
|
Software /
System Requirements
|
|
|
Software Included
|
Cisco
IOS IP Base
|
|
Dimensions
& Weight
|
|
|
Width
|
17.3
in
|
|
Depth
|
16.1
in
|
|
Height
|
1.7
in
|
|
Weight
|
16.53
lbs
|
|
Environmental
Parameters
|
|
|
Min Operating Temperature
|
32
°F
|
|
Max Operating Temperature
|
104
°F
|
|
Humidity Range Operating
|
10
- 90%
|
|
Lead time
|
2-3
business days
|
|
Shipment
|
DHL,
Fedex, Aramex, EMS or per request
|
