WS-C6509-E Overview
The Catalyst 6500 Series sets the new standard for IP communications and application delivery in enterprise campus and service provider networks by maximizing user productivity and enhancing operational control while providing unprecedented investment protection. As Cisco's premier intelligent multilayer modular switch, the Catalyst 6500 Series delivers secure, converged services, end-to-end, from the wiring closet to the core, to the data center, to the WAN edge.
WS-C6509-E Specification
|
General
|
|
|
Device Type
|
Switch
|
|
Enclosure Type
|
Desktop,
rack-mountable 15U
|
|
Features
|
Modular
design, hot swap module replacement
|
|
Expansion /
Connectivity
|
|
|
Expansion Slots
|
9
(total) / 9 (free) x expansion slot
|
|
Installed Modules Qty (Max)
|
0
(installed) / 9 (max)
|
|
Miscellaneous
|
|
|
MTBF
|
7
years
|
|
Compliant Standards
|
NEBS
level 3, FCC Class A certified, ETSI, VCCI, EN 60950, EN55022, UL 1950, IEC
825-1/EN 60825-1 class 1, IEC 60950, EN55024, CSA 22.2 No. 950, CISPR 22, ACA
TS001, AS/NZS 3260, AS/NZS 3548, FCC Part 15 A
|
|
Dimensions
& Weight
|
|
|
Width
|
17.5
in
|
|
Depth
|
18.1
in
|
|
Height
|
24.5
in
|
|
Weight
|
60.19
lbs
|
|
Manufacturer
Warranty
|
|
|
Service & Support
|
Limited
warranty - replacement - 90 days - response time: 10 days
|
|
Environmental
Parameters
|
|
|
Min Operating Temperature
|
32
°F
|
|
Max Operating Temperature
|
104
°F
|
|
Humidity Range Operating
|
10
- 90% (non-condensing)
|
|
Min Storage Temperature
|
-4
°F
|
|
Max Storage Temperature
|
149
°F
|
|
Warranty
|
1
year
|
|
Lead time
|
2-3
business days
|
|
Shipment
|
DHL,
Fedex, Aramex, EMS or per request
|
