WS-X4248-FE-SFP Overview
The Cisco Catalyst 4500 Series scalable, modular, high-density switches deliver high performance and integrated Layer 2, 3, and 4 switching with intelligent services for network control and resiliency. These switches offer a variety of Fast Ethernet and Gigabit Ethernet line cards that include fiber and copper interfaces optimized for desktops, branch office backbones, and servers for enterprise and commercial switching solutions, and service provider metropolitan Ethernet networks. Gigabit Ethernet line cards include cost-effective, high-performance 1000BASE-X gigabit interface converter (GBIC) and Small Form-Factor Pluggable (SFP)-based Gigabit Ethernet line cards and the high-density 10/100/1000BASE-T triple-speed autosensing, autonegotiating Gigabit Ethernet line cards.
WS-X4248-FE-SFP Specification
|
General
|
|
|
Device Type
|
Switch - 48 ports
|
|
Enclosure Type
|
Plug-in module
|
|
Subtype
|
Fast Ethernet
|
|
Ports
|
48 x 100 Mbit SFP
|
|
Features
|
Flow control
|
|
Compliant
Standards
|
IEEE 802.3, IEEE
802.3x, IEEE 802.3ah
|
|
Expansion /
Connectivity
|
|
|
Interfaces
|
48 x SFP
|
|
Miscellaneous
|
|
|
MTBF
|
687,828 hours
|
|
Compliant
Standards
|
NEBS
level 3, CISPR 22 Class A, EN 60950, IEC950, UL 1950, CSA 22.2 No. 950,
EN55022 Class A, AS/NZS 3548, RoHS, EN55024 Class A, EN 50121-4,
GR-1089-CORE, VCCI Class A, GR-63-CORE
|
|
Dimensions
& Weight
|
|
|
Width
|
14.3 in
|
|
Depth
|
10.7 in
|
|
Height
|
1.2 in
|
|
Environmental
Parameters
|
|
|
Min Operating
Temperature
|
32 °F
|
|
Max Operating
Temperature
|
104 °F
|
|
Humidity Range
Operating
|
10 - 90%
(non-condensing)
|
|
Min Storage
Temperature
|
-40 °F
|
|
Max Storage
Temperature
|
167 °F
|
|
Compatibility
Information
|
|
|
Designed For
|
Cisco Catalyst 4503,
4504, 4506, 4507R, 4510R
|
|
Warranty
|
1 year
|
|
Lead time
|
2-3 business days
|
|
Shipment
|
DHL, Fedex, Aramex,
EMS or per request
|
