WS-X45-SUP6-E Overview
The Cisco ® Catalyst ® 4500 Supervisor Engine 6-E with CenterFlex technology is an intelligent, high-performance, next-generation extension to the Cisco Catalyst 4500 Series optimized for customers deploying business-critical applications (Figure 1). Cisco developed application-specific integrated circuits (ASICs) specific to the Supervisor Engine 6-E that enable CenterFlex technology and deliver industry-leading centralized performance and configuration flexibility. CenterFlex technology enables granular optimization of real-time voice, video, and data communications to help ensure workforce productivity and profitability and customer success for organizations of all sizes.
WS-X45-SUP6-E Specification
|
Centralized switching capacity
|
320 Gbps
|
|
Per-slot switching capacity
|
24 Gbps
|
|
Throughput
|
250 Mpps for
IPv4
|
|
125 Mpps for IPv6
|
|
250 Mpps for L2 Bridging
|
|
IPv4 Routing entries
|
256000
|
|
IPv6 Routing entries
|
128000
|
|
Multicast routes
|
32000
|
|
CPU
|
1.3 GHz
|
|
CPU queues
|
64
|
|
Synchronous Dynamic RAM (SDRAM)
|
512 MB
upgradable to 1 GB
|
|
Nonvolatile RAM (NVRAM)
|
No through
Boot flash (64 MB)
|
|
Security and QoS hardware entries
|
128000
|
|
Cisco Network Admission Control (NAC) and Dynamic Host
Configuration Protocol (DHCP) Snooping entries
|
12000
|
|
MAC addresses
|
55000
|
|
Active VLANs
|
4096
|
|
Spanning Tree Protocol instances
|
10000
|
|
Switched virtual interfaces (SVIs)
|
4096
|
|
Switched Port Analyzer (SPAN)
|
Maximum of 8
sessions: ingress and or egress
|
|
Model No
|
WS-X45-SUP6-E
|
|
Warranty
|
1 year
|
|
Lead time
|
2-3 business days
|
|
Shipment
|
DHL, Fedex, Aramex,
EMS or per request
|
