WS-X45-SUP6L-E Overview
The Cisco® Catalyst® 4500 Supervisor Engine 6L-E (Figure 1) is a next-generation, Layer 3 supervisor addition to the Cisco Catalyst 4500 ESeries product line. The Supervisor 6L-E now supports full routing protocols, Open Shortest Path First (OSPF), Enhanced IGRP (EIGRP), Border
Gateway Protocol (BGP), and many other advanced features with the Enterprise Services package. (Note: You must use Cisco IOS® Software
Release 12.2(53)SG2 or later for Enterprise Services support).
WS-X45-SUP6L-E Specification
|
Model
info
|
WS-X45-SUP6L-E
|
|
Product
Description
|
Catalyst 4500
E-Series Supervisor 6L-E
|
|
Devide Tyde
|
Control Processor
|
|
Ports
|
2 * 10G * 2 Optics or
4 * 1G SFP
|
|
Console ports
|
10/100/1000 RJ-45
|
|
Centralized
switching capacity
|
280 Gbps
|
|
Per-slot
switching capacity
|
24 Gbps
|
|
FNF (Flexible
NetFlow) entries
|
128000
|
|
Forn Factor
|
Plug-in Module
|
|
Boot flash
|
64 MB and 128 MB
options
|
|
DRAM
|
512MB upgradable to 1
GB
|
|
Throughput
|
225 Mpps for IPv4
110 Mpps for IPv6
225 Mpps for L2 Bridging
|
|
Routing
entries
|
IPV4: 57,000
IPV6: 30,000
Multicast: 16,000
|
|
Security and
QoS hardware entries
|
64000
|
|
DHCP snooping
entries
|
3072
|
|
Warranty
|
1 year
|
|
Lead time
|
2-3 business days
|
|
Shipment
|
DHL, Fedex, Aramex,
EMS or per request
|
