WS-X6582-2PA Overview
WS-X6582-2PA is 2-port adapter bays Cisco Enhanced FlexWAN module for Cisco Catalyst 6500/7600 series with Supervisor Engine 2 and
Supervisor Engine 720 systems. WS-X6582-2PA enables intelligent WAN and MAN service scalability by supporting channelized WAN interfaces,
such as T1/E1, T3/E3, High-Speed Serial Interface (HSSI), ATM and POS (SDH). Moreover, WS-X6582-2PA offers high-end WAN aggregation which
includes Point-to-Point circuits, PPP, Frame Relay, HDLC, ATM or POS for Cisco Catalyst 6500/7600 series. The rich QoS features and distributed
processing attributes of the Cisco Enhanced FlexWAN module make it a cornerstone of a highly scalable WAN aggregation solution.
WS-X6582-2PA Specification
|
Model
info
|
WS-X6582-2PA
|
|
Product
Description
|
Cisco Catalyst 6500
Series Enhanced FlexWAN Module WS-X6904-40G-2T
|
|
Devide Tyde
|
2-port adapter bays
WAN and MAN service module
|
|
CPU
|
High performance
|
|
Number of CPUs
|
2 CPUs, one per bay
|
|
Memory
|
256MB per bay (512MB
max per bay)
|
|
Switch fabric
connectivity
|
Yes
|
Online
insertion and removal of
module
|
Yes
|
|
Supervisor
engines supported
|
Cisco Catalyst 6500
Series Supervisor Engine 2 and
Supervisor Engine 720 Systems
|
|
Software
compatibility
|
Cisco
IOS Software Release 12.2(17a)SXA or later
releases for Supervisor Engine 720
Cisco IOS Software Release 12.2(17a)SXB or later
releases for Supervisor Engine 2-based systems
|
|
Protocols
|
TCP,
IPv4, IPv6, Multiprotocol Label Switching
(MPLS), Ethernet over MPLS (EoMPLS), Frame Relay
over MPLS (FRoMPLS), ATM over MPLS (ATMoMPLS)
|
|
Features and
benefits
|
Higher
performance—Doubles the packet
forwarding performance over the previousgeneration FlexWAN module
Switch fabric connectivity—Allows system
scalability up to 720 Gbps by offering switch fabric
connectivity
Increased packet memory—Increases the memory
to 512 MB per bay, from 128 MB per bay supported
in the previous-generation FlexWAN; this enables
support of large routing tables, rich QoS features,
and increased scalability
OIR of the Cisco Enhanced FlexWAN module
Marking
Policing
Distributed traffic shaping (DTS)
Hierarchical traffic shaping
Network-based application recognition (NBAR)
|
|
Warranty
|
1 year
|
|
Lead time
|
2-3 business days
|
|
Shipment
|
DHL, Fedex, Aramex,
EMS or per request
|
