(ZG-AM10) Multi-Head Combination Weigher
1.Main Features:
* Amplitude can be adjusted freely and individually in running status, more friendly HMI.
* Multi-language operating interface.
* Mouse, USB and SD card compatible with touch screen.
* Instant display of the weigh hopper
2. Special Features:
* Modular electronic system makes maintenance easier and at lowest cost * AD card are inter-changeable ,easy to be replaced ； * Different authority managements, more user- friendly * HMI can be upgraded by U disk * Innovative Siemens PLC control system applied in the weigher and it makes machine more stable and low fault rate. Program update is much easier. (This technology has been granted patents. The patents number is: ZL 201020115548.8) * Application software can be upgraded by memory card. * Ethernet is available |
3.Specifications
Model | TY-P10L 2.5L |
Max. Cap.(g) | 10-1000g |
Weighing Accuracy | 0.1-1.5g |
Weighing speed | 70WPM |
Hopper Capacity | 2500ml |
Control system | PLC |
Operation Panel | 7 inch touch screen |
Power Supply | AC220V ±10%, 50Hz(60Hz) |
Packing Dimension (mm) | 1470(L)×1220(W)×1231(H) |
Gross Weight | 420KG |
Optional Devices | Dimple plate/Timing dipper/ Diverter device/10 inch touch screen/Teflon paint |
