EQ2xx10X-3LCD40

100Gb/s QSFP28 ER4 Lite Optical Transceiver

Ø Hot pluggable QSFP28 MSA form factor

Ø Compliant to Ethernet 100GBASE-ER4 Lite

Ø Supports 103.1Gb/s aggregate bit rate

Ø Up to 30km reach for G.652 SMF without FEC

Ø Up to 40km reach for G.652 SMF with  FEC

Ø Single +3.3V power supply

Ø Operating case temperature: 0~70oC

Ø Transmitter: cooled 4x25Gb/s LAN WDM EML TOSA (1295.56, 1300.05, 1304.58, 1309.14nm)

Ø Receiver: 4x25Gb/s APD ROSA

Ø 4x25G electrical interface (OIF CEI-28G-VSR)

Ø Maximum power consumption 4.5W

Ø Duplex LC receptacle

Ø RoHS-6 compliant

Applications

Ø 100GBASE-ER4 Ethernet Links

Ø Infiniband QDR and DDR interconnects

Ø Client-side 100G Telecom connections
