PERFORMANCE PARAMETERS

Light Source

Wavelength: 650±8nm Red Laser

Line

20Lines

Scan Rate

1180±5% Lines / Second

Scanning Angle Capability

Horizontal : 72°   Vertical:82°

Identifiable Contrast

≥33%

Decode Capability

EAN-8, EAN-13, UPC-A, UPC-E, Code 39, Code 93, Code 128, EAN 128, ISBN, ISSN, Codabar, Code 25 non-interleaved, Code 25 interleaved , Matrix 2 of 5, MSI, PostBarcode, etc

ELECTRICAL PARAMETERS

Port

USB2.0, PS/2,RS232

Voltage .Power

5VCD±12% 1.6W

Laser-level

Class1: IEC60825-1

EMC

FCC part 15class B, CE En55022B, VCCI, BSMI

LED Indicator

 Buzzer and bi-color light: Red-power, Blue-decoding Successfully

PHYSICAL PARAMETERS

Weight (pcs)

N.W: 468g/pcs G.W: 780g/pcs

Size (pcs)

Host: 115mm x114mm x152mm  Package: 245mm x165mmx132mm

Weight (Carton)

8.9kg

Package

10pcs

Size (Carton)

680mm*350mm*280mm

ENVIRONMENTAL PATAMETER

Crash resistant

Can withstand 1.2M free fall

Stands

IP54

Operating

0Degrees to 40 Degrees (32Fahrenheit to 104 Fahrenheit)

Storage Temperature

-20 Degrees to 40 Degrees (-4 Fahrenheit to 104 Fahrenheit)

Humidity

5% to 95% Relative humidity, Non-condensing
