Performance Parameter

Light Source

Visible Laser diode ,650nm

Decode Capability

EAN-8,EAN-13,UPC-A,UPC-E,Code 39,Code 93,Code 128,EAN128,Codaber, Industoal 2 of 5,Interleave 2 of 5,Matrix 2 of 5,MSI,etc.

Scanning Type

Multi-line Laser

Scan Rate

1400scans/second

Angle

5 directions

Resolution

0.127mm(5mil)@Code 39, PCS=90%

Print Contrast

≥30％(UPC/EAN 100%)

Error Rate

1/5million

Indicator

Loudspeaker (Tone and volume can be adjusted the original sound)

Interface Support

USB-HID，USB-COM，PS2，RS232

Physical Parameter

Dimension

L143mm*W74mm*H78mm

Weight

640g

Housing Materials

ABS+PC

Cable Parameter

2M

Electrical Parameter

Voltage

DC 5V±1%

Current

270mA

Environmental Parameter

Operating Temperature

-20℃~50℃

Storage Temperature

-20℃~+60℃

IP Level

IP54

Safety

Laser Safety

Class 1 to National Laser Safety Standards

Certificate

CE & FCC DOC compliance
