Novatec Hubs Carbon Road Tubular Wheels Specification
|
Material
|
Toray T700
|
Toray T700
|
|
Hubs
|
FS62CB Novatec Hub, 290g / pair
|
FS62CB Novatec Hub, 290g / pair
|
|
Inner/Out Width
|
23mm
|
25mmm
|
|
Depth
|
20mm, 23mm, 24mm, 38mm, 50mm, 88mm
|
30mm, 35mm, 38mm, 40mm, 45mm, 50mm, 55mm, 60mm 75mm, 80mm, 88mm, 120mm
|
|
Rim Type
|
Tubular
|
Tubular
|
|
Brake System
|
Rim Brake
|
Rim Brake
|
|
Rim Weight
|
250+/-15g, 420+/-15g, 290+/-15g, 330+/-15g, 380 +/-15g
|
310+/-15g, 330+/-15g, 345+/-15g, 380+/-15g, 395+/-15g, 410+/-15g, 420+/-15g, 475+/-15g, 500+/-15g, 520+/-15g, 530+/-15g, 670+/-15g
|
|
ERD
|
606, 524, 596, 568, 544, 468
|
586, 570, 564, 559, 549, 545, 530, 520, 490, 479, 469, 400
|
|
Weave
|
UD/3K/12K/Twill
|
UD/3K/12K/Twill
|
|
Finish
|
Matte/Glossy
|
Matte/Glossy
|
|
Spoke Hole
|
16/18/20/21/24H
|
16/18/20/21/24H
|
|
Max Spokes Tension
|
130 kgf
|
130 kgf
|
|
Max Tyre Pressure
|
120 Psi/8.5 Bars
|
120 Psi/8.5 Bars
|
|
Max Rider Weight
|
125 Kg
|
125 Kg
|
|
Warranty
|
2 Years
|
2 Years
|
1. Do I need to purchase Brake Pads?
No,each wheels incl 2 pair superroad brake pads. (Only wheels)
2. Should I run different tyre pressures on your rims?
Different wider rim need different size tyre, please confirm with our sales before your order.
