The 3 way T type ball valve owns flange connection, gearbox, ss304 body, ball and stem. The 3 inch flanged ball valve features in its T type three way ports which could connect any pair of ports or three ports together.
Quick Detail
|
Type
|
Ball Valve
|
|
Size
|
3"
|
|
Pressure
|
ANSI 300
|
|
Construction
|
Three Way
Ball Valve
|
|
Connection
|
Flanged Connection
|
|
Operation
Mode
|
Gearbox
|
|
Body
Material
|
A182 F304
|
|
Manufacture
and Design
|
API 6D
|
|
Pressure
& Temp
|
ASME B16.34
|
|
End to End
Code
|
ASME B16.10
|
|
End
Connection
|
ASME B16.5
|
|
Inspection
|
API 6D,
API 598
|
|
Temperature
Range
|
-29℃~+200℃
|
|
Medium
|
WOG
|
Related Knowledge
What is the difference between T port and L port 3-way ball valve?
Normally speaking, 3-way ball valve can be divided into T type and L type.
A T port three-way ball valve can connect any two ports, and even connect all three ports together at the same time. However, an L port three-way ball valve can only connect the center port with either side port or disconnect three ports.
