300KVA Sweden Volvo Penta TAD1341GE Open/Silent/Trailer Type Fuel Engine Diesel Generator
Volvo Engine
VOLVO diesel generator set is environment-friedly generator, it meets the emssion standard EU II or III and also the EPA.It adopts the advanced design idea and technology, featured with good economic performance, low oil consumption, small volume, compact structure, great power and running stabilty.
Engine Specifications:
|
Engine Model
|
TAD1341GE
|
|
Engine manufacturer
|
VOLVO
|
|
Number of Cylinders
|
6 cylinders
|
|
Cylinders arrangement
|
Vertical in LINE
|
|
Cycle
|
4 stroke
|
|
Aspiration
|
Naturally
|
|
Bore×Stroke
|
131mm x158mm
|
|
Displacement
|
7.15L
|
|
Compression ratio
|
16.5:1
|
|
Prime Power/Speed
|
271KW/1500rpm
|
|
Standby Power/Speed
|
298KW/1500rpm
|
|
Speed Governor
|
electrical
|
|
Cooling System
|
Forced water cooling cycle
|
|
Steady speed droop
|
≤1%
|
|
Total lubrication system capacity
|
20L
|
|
Fuel Consumption at 100% Load
|
201 g/kw.h
|
|
Starter Motor
|
DC24V,
|
|
Alternator
|
AC24V
|
Alternator
|
Alternator brand
|
Stamford, Marathon, Leroy Somer, Mecc-alte, TWGII Series
|
|
Prime power
|
300kva
|
|
Frequency/speed
|
50HZ/1500rpm (60Hz/1800rpm)
|
|
Exciter type
|
Single bearing, Brushless, Self-excited
|
|
Power factor
|
0.8
|
|
Voltage adjust range
|
≥5%
|
|
Voltage regulation NL-FL
|
≤±1%
|
|
Insulation Grade
|
H
|
|
Protection Grade
|
IP23
|
Control panel
|
Brand
|
Deepsea/ComAp/Smartgen
|
|
The control module gives digital readouts of:
Generator voltage;
Output frequency;
Engine speed;
Battery voltage;
Engine hours run.
The control module has indicators for failure
information:
Overspeed/underspeed,
Emergency stop
Low oil pressure;
High water temperature
Failure to start
Battery charger failure
Automatic shutdown occurs under:
Low engine oil pressure;
High engine water temperature;
Overspeed/underspeed;
Failure to start after three attempts.
|
|
Main features of Volvo diesel generator
<1>. Multi-cylinder-line or vee engines, direct injection
<2>. Turbocharged, water cooled, cooling fan
<3>. 24V DC starter, mechanical or electronic governor
<4>. Low fuel consumption and low discharge
<5>. High efficiency
<6>. Maintaining easily and low maintenance expense
Specifications of Volvo diesel generator
|
Genset model
|
Engine Model
|
Prime power/Standby power
|
fuel Consumption
|
size(mm)
|
Weight (Kg)
|
|
KVA
|
KW
|
g/kw.h
|
Length
|
Width
|
Height
|
|
AV95
|
TD520GE
|
85/94
|
68/75
|
213
|
1900
|
680
|
1350
|
1050
|
|
AV110
|
TAD520GE
|
100/110
|
80/88
|
206
|
2000
|
740
|
1350
|
1150
|
|
AV140
|
TD720GE
|
130/142.5
|
104/114
|
211
|
2200
|
750
|
1400
|
1430
|
|
AV165
|
TAD720GE
|
151/166
|
121/133
|
197
|
2530
|
880
|
1400
|
1500
|
|
AV205
|
TAD721GE
|
188/206
|
150/165
|
204
|
2530
|
1025
|
1800
|
1540
|
|
AV228
|
TAD722GE
|
206/228
|
165/182
|
205
|
2650
|
1025
|
1800
|
1620
|
|
AV275
|
TAD940GE
|
250/275
|
200/220
|
201
|
3000
|
1120
|
1600
|
2120
|
|
AV305
|
TAD940GE
|
278/305
|
222/244
|
201
|
3000
|
1120
|
1600
|
2190
|
|
AV358
|
TAD941GE
|
325/358
|
260/286
|
202
|
3000
|
1120
|
1600
|
2400
|
|
AV400
|
TAD1241GE
|
375/412.5
|
300/330
|
198
|
3000
|
1120
|
1600
|
2850
|
|
AV450
|
TAD1242GE
|
409/450
|
327/360
|
198
|
3000
|
1120
|
1600
|
2850
|
|
AV518
|
TAD1630GE
|
470/518
|
376/414
|
209
|
3500
|
1100
|
1665
|
3050
|
|
AV508
|
TAD1640GE
|
461/507.5
|
369/406
|
194
|
3300
|
1120
|
1587
|
3200
|
|
AV560
|
TAD1641GE
|
509/560
|
407/448
|
198
|
3300
|
1120
|
1587
|
3300
|
|
AV628
|
TAD1642GE
|
570/627.5
|
456/502
|
200
|
3300
|
1120
|
1587
|
3400
|
|
AV688
|
TAD1643GE
|
625/687.5
|
500/550
|
199
|
3400
|
1400
|
2050
|
3700
|
FAQ
1.Are you a factory or trading company?
A: We are a factory.
2.What is the material of your products?
A: Iron, Steel, plastic, etc.
3.How about quality control in your factory?
A: AI people are always paying great attentions to quality controlling from the beginning to the end.
4.How about your guarantee?
A: Our warranty period is 1 year or 1000 running hours, whichever comes first.
